GLASS PASSIVATED

VOLTAGE RANGE  50 to 1000 Volts   CURRENT 3.0 Amperes

RECTRON

SEMICONDUCTOR

TECHNICAL  SPECIFICATION

FEATURES

* High reliability
* Low  leakage
* Low forward voltage drop
* High current capability
* Glass passivated junction

MECHANICAL DATA

* Case: Molded plastic
* Epoxy: Device has UL flammability classification 94V-O
* Lead: MIL-STD-202E method 208C guaranteed
* Mounting position: Any
* Weight: 1.18 grams

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

o

C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

1N5400G

THRU

1N5408G

DO-201AD

MAXIMUM RATINGS (At T

A

 = 25

o

C unless otherwise noted)

NOTES : Measured at 1 MH

Z

 and applied reverse voltage of 4.0 volts

ELECTRICAL CHARACTERISTICS (At T

A

 = 25

o

C unless otherwise noted)

JUNCTION PLASTIC RECTIFIER

Dimensions in inches and (millimeters)

2002-12

at Rated DC Blocking Voltage

CHARACTERISTICS

Maximum Full Load Reverse Current Average, Full Cycle
.375” (9.5mm) lead length at T

L

 = 75

o

C

V

F

SYMBOL

I

R

UNITS

1.1

5.0

30

uAmps

uAmps

Maximum DC Reverse Current

Maximum Instantaneous Forward Voltage at 3.0A DC

Volts

@T

A

= 25

o

C

@T

A

= 100

o

C

1N5400G 1N5401G 1N5402G 1N5404G 1N5406G 1N5407G 1N5408G

300

RATINGS

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current
.375” (9.5mm) lead length at T

L

 = 105

o

C

Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)

Typical Junction Capacitance (Note)

Operating and Storage Temperature Range

SYMBOL

V

RRM

V

DC

I

O

I

FSM

C

J

T

J

, T

STG

V

RMS

Volts

Volts

Volts

Amps

3.0

150

40

-55 to + 150

Amps

pF

0

C

UNITS

Typical Thermal Resistance

R

θ

J A

30

0

C / W

50

100

200

400

600

800

1000

70

35

140

280

420

700

560

50

200

400

600

800

1000

100

1N5400G 1N5401G 1N5402G 1N5404G 1N5406G 1N5407G 1N5408G

.220 (5.6)

.197 (5.0)

DIA.

.052 (1.3)
.048 (1.2)

DIA.

1.0 (25.4)

MIN.

.335 (8.5)

.375 (9.5)

1.0 (25.4)

MIN.

RECTRON

RATING AND CHARACTERISTIC CURVES ( 1N5400G THRU 1N5408G )

FIG. 1 - TYPICAL FORWARD CURRENT

AVERAGE FORWARD  CURRENT, (A)

LEAD TEMPERATURE, (     )

DERATING CURVE

5

4

3

2

1

0

0

25

50

75

100

125 150

175

Single Phase
Half Wave 60Hz
Resistive or
Inductive Load

FIG. 3 - MAXIMUM NON-REPETITIVE FORWARD

 PEAK FORWARD SURGE CURRENT, (A)

NUMBER OF CYCLES AT 60Hz

SURGE CURRENT

1

2

4

6 8 10

20

40 60 80100

250

200

150

100

 50

0

8.3ms Single Half Sine-Wave
(JEDED Method)

JUNCTION CAPACITANCE,

(pF

)

FIG. 5 - TYPICAL JUNCTION CAPACITANCE

REVERSE VOLTAGE, ( V )

200

100

60

40

20

10

6
4

2

1

.1

.2

.4

1.0

2

4

10

20

40

100

TJ = 25

FIG. 2 - TYPICAL INSTANTANEOUS FORWARD

 CHARACTERISTICS

INSTANTANEOUS FORWARD

INSTANTANEOUS FORWARD VOLTAGE, (V)

TJ = 25
Pulse Width=300us
1% Duty Cycle

CURRENT, (A)

.6

.8

1.0

1.2

1.4

1.5

20
10

4
2

1.0

.4
.2
.1

.04
.02
.01

TJ = 25

FIG. 4 - TYPICAL REVERSE CHARACTERISTICS

INSTANTANEOUS REVERSE CURRENT, (uA)

PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)

0

20

40

60

80

100

120

140

.01

.04

.1

.4

10

1.0

4
