Data Sheet

SL15 16004

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 4.40

A
J

50

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 100

J

Ω

0.19

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.54

Ω

°c

172.00

Body Temperature at 100% Max Current:

Dissipation Constant: 15.9

mw/°c
Sec.

54

Thermal Time Constant:

Material Type (for Beta and Curve): H

D: 15.0

Max
Max

4.5

T:

Lead Diameter

1.0

Nom
Nom

7.8

S:

L: 38.0

Nom

Max

5.0

Coating Lead Run Down

(straight Leads)

B: 7.50

Nom
Nom

2.82

C:

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 16.0

Ω

±

20 %
