Data Sheet

SL32 1R030

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 30.00

A
J

160

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 270

J

Ω

0.01

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.05

Ω

°c

214.00

Body Temperature at 100% Max Current:

Dissipation Constant: 45.4

mw/°c
Sec.

245

Thermal Time Constant:

Material Type (for Beta and Curve): C

D: 31.0

max
max

5.0

T:

Lead Diameter

1.0

nom
nom

7.8

S:

L: 38.0

nom

max

5.0

Coating Lead Run Down

(straight Leads)

B: 7.80

nom
nom

3.82

C:

µf

11,114

Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:

µf

2,778

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 1.0

Ω

±

20 %

SL32 1R030

11/11/2008

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com

Drawn by:

Date:

Approved By:

a

Revison:
