canfield connector

8510 Foxwood Court

Youngstown, Ohio  44514

(330) 758-8299   Fax: (330) 758-8912

www.canfieldconnector.com

4

SOLENOID VALVE CONNECTORS

GENERAL PRODUCT OVERVIEW

SERIES 5000



Dimensional Data

ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE NOTED  (COMPLETE DIMENSIONAL INFORMATION IS PROVIDED ON INDIVIDUAL PAGES)



General Description

The ISO and 8mm Sub-Micro connectors are made according to DIN 43650 / ISO 4400, EN175301-803:2000.  The

MINI and 9.4mm Sub-Micro connectors are industry standards.  All are used as protective enclosures for electrical con-

nection in conjunction with hydraulic and pneumatic solenoid valves.  These connectors offer distinct advantages over

“hardwired” solenoid valves because of their modular design.  Used where rapid installation and service are a must.

Better than molded construction when special wire is needed or when using one long wire run.

MINI

ISO

DIN 43650 Form "A" / ISO 4400,

EN175301-803:2000

Sub-Micro

(8mm) DIN 43650 Form "C" / ISO 4400,

EN175301-803:2000

PG9

3/8" Conduit

1/2" Conduit

PG9 / HT PG9

PG11 / HT PG11

1/2" Conduit

HT 1/2" Conduit

8mm Strain Relief

*Ground spade offset by 0.2mm toward pin 1.

8mm 1/2" Conduit

*Ground spade offset by 0.2mm toward pin 1.

9.4mm Strain Relief

9.4mm 1/2" Conduit

40

27

21 11

PG9

58

27

21 11

3/8"

NPTF

1/2"

NPTF

44

27

21 11

40

26.5

26.5 18

PG9

40

26.5

26.5 18

PG11

40

26.5

26.518

1/2"

NPTF

40

26.5

26.518

1/2"

NPTF

23.8

37

16

16 8

37

16

16 9.4

47

16

16 9.4

47

16

16 8

1/2"

NPTF

1/2"

NPTF

5

0

0

0

G

E

N

5

Ordering Example:



  5100-1010000

    Ground down, unlighted, nitrile gasket, MINI strain relief

    PG9 connector, 2+ ground contacts, standard house

Gasket

1 - Nitrile

2 - Silicone

3 - Nitrile profile**

Each connector kit contains fastening hardware and gasket assembly.

*

NOT

 Available in MINI

**

NOT

 Available in Sub-Micro

Not all combinations are available. Consult factory for details.

† High Top Housing for easy wiring.

Contacts

0 - 2+ ground

1 - 3+ ground*

Housing Color

0 - Standard “B”

1 - Gray “A”

Connector Types

01 - MINI strain relief PG9

02 - MINI 3/8" conduit

03 - MINI 1/2" conduit

08 - ISO strain relief PG9

09 - ISO strain relief PG11

10 - ISO 1/2" conduit

11 - ISO HT strain relief PG9

†

12 - ISO HT strain relief PG11

†

13 - ISO HT 1/2" conduit

†

90 - Sub-Micro PG7 DIN interface (8mm)

91 - Sub-Micro 1/2" conduit interface (8mm)

95 - Sub-Micro 1/2" conduit (9.4mm)

99 - Sub-Micro strain relief PG7 (9.4mm)

Ordering Information

Orientation

1 - Ground down

Other ground orientations available.

Please consult factory.

Lighting Specification

0 - Unlighted

3 - 6 - 48V AC/DC 50/60 Hz

7 - 48 - 120 VDC

  100 - 240 VAC 50/60 Hz

5       0       -                           0  0

Use a prefix of "G" for Individually Bagged

NOTE:  When using MAC Valves with 9.4mm Sub-Micro,



consult our factory.

MAC is the registered trademark of MAC Valves, Inc.

Consult factory for available versions listed

by Canadian Standards Association for use

with certified electrical equipment.

C

US

5

0

0

0

G

E

N

canfield connector

8510 Foxwood Court

Youngstown, Ohio  44514

(330) 758-8299   Fax: (330) 758-8912

www.canfieldconnector.com

6

1 = (+) Positive, High

2 = (-) Negative, Neutral

       =  Chassis Ground

Normal polarity:



Dimensional Data

ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE NOTED

26.5

40

1/2" NPTF

26.5

33.1

18

1.5

gasket

M3

23.8

26.5

44.7

1/2"NPTF

26.5

27.9

18

1.5

gasket

M3

4.4

26.5

40

PG9/PG11

26.5

33.1

18

1.5

gasket

M3

6.2 min.

26.5

40

PG9/PG11

26.5

26.5

18

1.5

gasket

M3

6.2 min.



General Description

Canfield Connector’s Series 5000 ISO connector connects solenoid valves using the DIN

43650 Form "A" / ISO 4400, EN175301-803:2000 specification.  This standard permits in-

dustry interchangeability and has been embraced by the solenoid valve industry worldwide.

Features include the ability for the user to wire the connector into existing installations or the

connector can be prewired at the factory.  Wire connections are made inside the connector

housing and the wire inlet is either PG9, PG11 or 1/2" conduit.  Canfield has added to this line

with the HT (High Top) housing.  The HT accommodates the user with more room for larger

wire diameters.  The standard ISO connectors are still available for those applications with

space constraints.  Maximum current rating is 10 Amps with a maximum conductor size of

14 AWG with an outer jacket not to exceed .410 inches diameter. There are CSA approved

versions as well as versions with indicator lights depicting the “on” state.  The connectors

are NEMA 4 and IP 65 environment rated.

ISO

SOLENOID VALVE CONNECTOR

SERIES 5000

** HT refers to High Top - Larger connector for larger wire gauge and easy installation.

Wiring Information

PG9 / PG11

HT** PG9 / PG11

1/2" Conduit

HT** 1/2" Conduit

5

0

0

0

I

S

O

7



Ordering Information

Connector Type

08 - ISO strain relief PG9

09 - ISO strain relief PG11

10 - ISO 1/2" conduit

11 - ISO HT strain relief PG9**

12 - ISO HT strain relief PG11**

13 - ISO HT 1/2" conduit

Gasket

1 - Nitrile

2 - Silicone

3 - Nitrile profile

Lighting Specification

0 - Unlighted

3 -  6 - 48V AC/DC 50/60 Hz

7 -  48 - 120 VDC

  100 - 240 VAC 50/60 Hz

Contacts

0 - 2 + ground

1 - 3 + ground

Housing Color

0 - Black “B” standard.  Translucent if lighted.

1 - Gray “A”

**

HT refers to High Top - Larger connector for

larger wire gauge and easy installation.

Ordering Example:

  5100-1080000



Ground down, nitrile gasket, ISO strain relief PG9,

    2+ ground contacts, black house

Derating Curve



Technical Data

• The cable outlet can be assembled in 90°



 increments

• Color:  black, gray or translucent for lighted styles

• Cable diameter:  PG9 - .236 to .315 inches O.D.





PG11 - .315 to .394 inches O.D.





1/2" Conduit - .410 inches max.

• Cross section of the conductor wire max.:  14 AWG

• Maximum approved current:  10 Amps

• Rated voltage max.:  300 VDC / 250 VAC 50/60 Hz

• No. of contacts:  2+ ground





3+ ground

• Environmental protection:  NEMA 4 and IP 65 dust tight

  and water resistant

• Maximum rated temperatures for gaskets:





Nitrile gasket:  -25° to +90°C





Silicone gasket:  -40° to +125°C

5       0       -                           0  0

SERIES 5000 ISO

Can-Pak



Part Number

Qty

CP-5100-1080000-025

25

CP-5100-1080000-100

100

CP-5100-1100000-025

25

CP-5100-1100000-100

100

CP-5103-1080000-025

25

CP-5103-1080000-100

100

CP-5107-1080000-025

25

CP-5107-1080000-100

100

Each connector kit contains fastening

hardware and gasket assembly.

Use a prefix of "G" for Individually Bagged

Consult factory for available versions listed

by Canadian Standards Association for use

with certified electrical equipment.

C

US

Orientation

1 - Ground down

Other ground orientations available.

Please consult factory.

5

0

0

0

I

S

O

canfield connector

8510 Foxwood Court

Youngstown, Ohio  44514

(330) 758-8299   Fax: (330) 758-8912

www.canfieldconnector.com

8

Ground Down

1 = (+) Positive, High

2 = (-) Negative, Neutral

       =  Chassis Ground

Normal polarity:

Ground Up



Dimensional Data

ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE NOTED



General Description

The Canfield Connector field wireable MINI solenoid valve connector is a high quality in-

terconnection device for use with solenoid valves and pressure switches.  The connector

features a PG9 strain relief, 3/8" or 1/2" conduit wire pass through, all with screw terminals

for wire connections.  The MINI accommodates wire from .240" to .410" diameter as a

standard with an AWG of 14 maximum.  Environment resistance of NEMA 4 / IP 65 along

with versions which are CSA approved ensure long trouble free service.  Current maximum

of 10 Amps and the temperature rating of -40° to +125°C encompasses most applications.

The interface is an industry standard.

MINI

SOLENOID VALVE CONNECTOR

SERIES 5000

27

21 11

PG9

27.9

1.5

40

gasket

M3

4

4.9 min.

27

21 11

3/8" NPTF

30

1.5

58

gasket

M3

4

31.4

1.5

44

gasket

M3

4

27

21 11

1/2" NPTF

Wiring Information

Strain Relief

3/8" Conduit

1/2" Conduit

5

0

0

0

M

I

N

I

9

Each connector kit contains fastening

hardware and gasket assembly.

Lighting Specification

0 -  Unlighted

3 -  6 - 48V AC/DC 50/60 Hz

7 -  48 - 120 VDC

  100 - 240 VAC 50/60 Hz

Housing Color

0 - Black “B” standard.  Translucent if lighted.

1 - Gray “A”

Connector Types

01 - MINI strain relief PG9

02 - MINI 3/8" conduit

03 - MINI 1/2" conduit

Gasket

1 - Nitrile

2 - Silicone

3 - Nitrile profile



Ordering Information

5       0       -                  0       0  0

Derating Curve



Technical Data

• The cable outlet can be assembled in 180°



 increments

• Color:  black, gray or translucent for lighted styles

• Cable diameter:  PG9 - .236 to .315 inches O.D.



3/8" & 1/2" Conduit - .410 inches max.

• Cross section of the conductor wire max.:  14 AWG

• Rated voltage max.:  300 VDC / 250 VAC 50/60 Hz

• Maximum approved current:  10 Amps

• No. of contacts:  2+ ground

• Environmental protection:  NEMA 4 and IP 65 dust tight

  and water resistant

• Maximum rated temperatures for gaskets:



Nitrile gasket -25° to +90°C



Silicone gasket -40° to +125°C

Use a prefix of "G" for Individually Bagged

Ordering Example:



  5100-1010000

    Ground down, unlighted, nitrile gasket, MINI strain

    relief PG9 connector, black house

SERIES 5000 MINI

Can-Pak

Part Number

Qty

CP-5100-1010000-025

25

CP-5100-1010000-100

100

CP-5100-1030000-025

25

CP-5100-1030000-100

100

CP-5103-1010000-025

25

CP-5103-1010000-100

100

CP-5107-1010000-025

25

CP-5107-1010000-100

100

CP-5163-1010000-010

10

CP-5163-1010000-050

50

CP-5167-1010000-010

10

CP-5167-1010000-050

50

Consult factory for available versions listed

by Canadian Standards Association for use

with certified electrical equipment.

C

US

Orientation

1 - Ground down

Other ground orientations available.

Please consult factory.

5

0

0

0

M

I

N

I

canfield connector

8510 Foxwood Court

Youngstown, Ohio  44514

(330) 758-8299   Fax: (330) 758-8912

www.canfieldconnector.com

10

1 = (+) Positive, High

2 = (-) Negative, Neutral

       =  Chassis Ground

Normal polarity:



Dimensional Data

ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE NOTED

SERIES 5000

SUB-MICRO

SOLENOID VALVE CONNECTOR



General Description

Canfield Connector’s Series 5000 Sub-Micro connector is made to connect solenoid valves

using the DIN 43650 Form “C”, EN175301-803:2000 (8mm pin center) and the industry

standard 9.4mm pin center. These standards permit industry interchangeability and have

been embraced by the solenoid valve industry worldwide. Features include the ability for

the user to wire the connector into existing installations or the connector can be prewired

at the factory. Wire connections are made inside the connector housing. The wire inlet is

either PG7 or 1/2" conduit. Maximum current rating is 6 amps with a maximum conductor

size of 20 gauge with an outer jacket not to exceed .260 inches diameter. There are ver-

sions with indicator lights depicting the “on” state. The connectors are NEMA 4 and IP 65

environment rated.

Wiring Information

PG7, 8mm center

PG7, 9.4mm center

1/2" Conduit, 9.4mm center

1/2" Conduit, 8mm center

*Ground spade offset by 0.2mm toward pin 1.

16

8

16

PG7

37

25.5

29

M2.5

16

9.4

16

PG7

37

25.5

29

M3

16

8

16

25.4

47

25.5

29.5

1/2" NPTF

M2.5

16

9.4

16

25.4

47

25.5

29.5

1/2" NPTF

M3

5

0

0

0

S

M

11

Each connector kit contains screw,

washer and gasket assembly.

5       0       -                            0  0



Ordering Information

Housing Color

0 - Black “B” standard.  Translucent if lighted.

1 - Gray “A”

Contacts

0 - 2 +ground

1 - 3 +ground*

Lighting Specification

0 -  Unlighted

3 -  6 - 48V AC/DC 50/60 Hz

7 -  48 - 120 VDC

  100 - 240 VAC 50/60 Hz

Gasket

1 - Nitrile

2 - Silicone

Connector Type

90 - Sub-Micro strain relief PG7 DIN interface (8mm)

91 - Sub-Micro 1/2" conduit DIN interface (8mm)

95 - Sub-Micro 1/2" conduit (9.4mm)

99 - Sub-Micro strain relief PG7 (9.4mm)

*

3+ ground

 NOT

 available

in lighted version.



Technical Data

•  The cable outlet can be assembled in 90°



 increments

•  Color:  black, gray or translucent for lighted styles

•  Cable diameter:  PG7 - .157 - .236 inch O.D.



1/2" Conduit 8mm & 9.4mm - .250 inch max.

•  Cross section of the conductor wire max.:  20 AWG

•  Rated voltage max.:  250 VAC 50/60 Hz or VDC

•  Maximum approved current:  6 Amps

•  No. of contacts:  2+ ground,



3+ ground (

NOT

 available on lighted units)

•  Environmental protection:  NEMA 4 and IP 65 dust tight

  and water resistant

•  Maximum rated temperatures for gaskets:



Nitrile gasket:  -25° to +90°C



Silicone gasket:  -40° to +125° C

Derating Curve

Use a prefix of "G" for Individually Bagged

NOTE:  When using MAC Valves with 9.4mm Sub-Micro,



consult our factory.

Ordering Example:



  5100-1900000

    Ground down, unlighted, nitrile gasket, Sub-Micro strain

    relief PG7 DIN interface, 2+ ground contacts, black house

SERIES 5000 SUB-MICRO

Can-Pak

Part Number

Qty

CP-5100-1900000-025

25

CP-5100-1900000-100

100

CP-5100-1990000-025

25

CP-5100-1990000-100

100

CP-5103-1900000-025

25

CP-5103-1900000-100

100

CP-5103-1990000-025

25

CP-5103-1990000-100

100

CP-5107-1900000-025

25

CP-5107-1900000-100

100

CP-5107-1990000-025

25

CP-5107-1990000-100

100

Consult factory for available versions listed

by Canadian Standards Association for use

with certified electrical equipment.

C

US

Orientation

1 - Ground down

Other ground orientations available.

Please consult factory.

5

0

0

0

S

M
