SEE PAGE 4 FOR LEAD LENGTHS UNDER (LEAD MATERIAL)

X391L

301 WEST O STREET

•

OGALLALA, NE 69153

Phone: (308) 284-3611

e-mail: sales@ascapacitor.com

Fax: (308) 284-8324

web: www.ascapacitor.com

240VAC

CAP

(µF)

± .063”

(MM)

± .063”

(MM)

CAP

(µF)

± .063”

(MM)

± .063”

(MM)

14.0

1.20”

(30mm)

2.70”

(68mm)

36.0

1.60”

(40mm)

3.60”

(92mm)

15.0

1.60”

(40mm)

2.70”

(68mm)

40.0

1.60”

(40mm)

3.60”

(92mm)

17.5

1.60”

(40mm)

2.70”

(68mm)

45.0

1.60”

(40mm)

3.60”

(92mm)

20.0

1.60”

(40mm)

2.70”

(68mm)

48.0

1.80”

(45mm)

3.60”

(92mm)

22.5

1.60”

(40mm)

2.70”

(68mm)

52.0

1.80”

(45mm)

3.60”

(92mm)

28.0

1.60”

(40mm)

2.70”

(68mm)

55.0

1.80”

(45mm)

3.60”

(92mm)

30.0

1.60”

(40mm)

2.70”

(68mm)

56.0

1.80”

(45mm)

3.60”

(92mm)

34.0

1.60”

(40mm)

3.60”

(92mm)

62.0

1.80”

(45mm)

3.60”

(92mm)

35.0

1.60”

(40mm)

3.60”

(92mm)

*** WARNING, THIS PRODUCT IS NOT PROTECTED, IT IS THE USER RESPONSIBILITY TO

PROVIDE CIRCUIT PROTECTION. FAILURE TO DO SO COULD RESULT IN FIRE***

PAGE 1 OF 4

METALLIZED POLYPROPYLENE
DRY CAPS FOR HID LIGHTING

LL - SEE PAGE 4 FOR LEAD LENGTHS UNDER (LEAD MATERIAL)

X391L

301 WEST O STREET

•

OGALLALA, NE 69153

Phone: (308) 284-3611

e-mail: sales@ascapacitor.com

Fax: (308) 284-8324

web: www.ascapacitor.com

280VAC

CAP

(µF)

± .063”

(MM)

± .063”

(MM)

CAP

(µF)

± .063”

(MM)

± .063”

(MM)

5.0

1.20”

(30mm)

2.20”

(55mm)

22.5

1.60”

(40mm)

3.60”

(92mm)

6.0

1.20”

(30mm)

2.20”

(55mm)

24.0

1.60”

(40mm)

3.60”

(92mm)

7.0

1.20”

(30mm)

2.70”

(68mm)

24.5

1.60”

(40mm)

3.60”

(92mm)

8.0

1.20”

(30mm)

2.70”

(68mm)

25.0

1.60”

(40mm)

3.60”

(92mm)

10.0

1.20”

(30mm)

2.70”

(68mm)

26.0

1.60”

(40mm)

3.60”

(92mm)

12.0

1.60”

(40mm)

2.70”

(68mm)

28.0

1.60”

(40mm)

3.60”

(92mm)

13.0

1.60”

(40mm)

2.70”

(68mm)

30.0

1.60”

(40mm)

3.60”

(92mm)

14.0

1.60”

(40mm)

2.70”

(68mm)

32.0

1.60”

(40mm)

3.60”

(92mm)

16.0

1.60”

(40mm)

2.70”

(68mm)

35.0

1.80”

(45mm)

3.60”

(92mm)

17.5

1.60”

(40mm)

2.70”

(68mm)

40.0

1.80”

(45mm)

3.60”

(92mm)

18.5

1.60”

(40mm)

2.70”

(68mm)

45.0

1.80”

(45mm)

4.60”

(117mm)

20.0

1.60”

(40mm)

2.70”

(68mm)

48.0

1.80”

(45mm)

4.60”

(117mm)

21.0

1.60”

(40mm)

2.70”

(68mm)

55.0

1.80”

(45mm)

4.60”

(117mm)

22.0

1.60”

(40mm)

3.60”

(92mm)

56.0

1.80”

(45mm)

4.60”

(117mm)

*** WARNING, THIS PRODUCT IS NOT PROTECTED, IT IS THE USER RESPONSIBILITY TO

PROVIDE CIRCUIT PROTECTION. FAILURE TO DO SO COULD RESULT IN FIRE***

PAGE 2 OF 4

METALLIZED POLYPROPYLENE
DRY CAPS FOR HID LIGHTING

LL - SEE PAGE 4 FOR LEAD LENGTHS UNDER (LEAD MATERIAL)

X391L

301 WEST O STREET

•

OGALLALA, NE 69153

Phone: (308) 284-3611

e-mail: sales@ascapacitor.com

Fax: (308) 284-8324

web: www.ascapacitor.com

330VAC

400VAC

CAP

(µF)

± .063”

(MM)

± .063”

(MM)

CAP

(µF)

± .063”

(MM)

± .063”

(MM)

5.0

1.20”

(30mm)

2.20”

(55mm)

10.0

1.60”

(40mm)

2.70”

(68mm)

7.0

1.20”

(30mm)

2.70”

(68mm)

12.0

1.60”

(40mm)

3.60”

(92mm)

10.0

1.60”

(40mm)

2.70”

(68mm)

15.0

1.60”

(40mm)

3.60”

(92mm)

12.0

1.60”

(40mm)

2.70”

(68mm)

18.0

1.60”

(40mm)

3.60”

(92mm)

13.0

1.60”

(40mm)

2.70”

(68mm)

20.0

1.60”

(40mm)

3.60”

(92mm)

15.0

1.60”

(40mm)

2.70”

(68mm)

20.5

1.80”

(45mm)

3.60”

(92mm)

16.0

1.60”

(40mm)

3.60”

(92mm)

24.0

1.80”

(45mm)

3.60”

(92mm)

17.5

1.60”

(40mm)

3.60”

(92mm)

30.0

1.80”

(45mm)

4.60”

(117mm)

18.5

1.60”

(40mm)

3.60”

(92mm)

20.0

1.60”

(40mm)

3.60”

(92mm)

24.5

1.80”

(45mm)

3.60”

(92mm)

26.0

1.80”

(45mm)

3.60”

(92mm)

28.0

1.80”

(45mm)

3.60”

(92mm)

*** WARNING, THIS PRODUCT IS NOT PROTECTED, IT IS THE USER RESPONSIBILITY TO

PROVIDE CIRCUIT PROTECTION. FAILURE TO DO SO COULD RESULT IN FIRE***

PAGE 3 OF 4

METALLIZED POLYPROPYLENE
DRY CAPS FOR HID LIGHTING

X391L

301 WEST O STREET

•

OGALLALA, NE 69153

Phone: (308) 284-3611

e-mail: sales@ascapacitor.com

Fax: (308) 284-8324

web: www.ascapacitor.com

PAGE 4 OF 4

GENERAL SPECIFICATIONS

PHYSICAL CHARACTERISTICS

CONSTRUCTION:

NON-INDUCTIVE WOUND METALLIZED POLYPROPYLENE.

CASE:

ROUND THERMOPLASTIC CASE (UL94 V-0) WITH EPOXY FILL.

LEAD MATERIAL:

18 AWG STRANDED WIRE LEADS. 8 INCH STANDARD (LL), OTHER LEAD LENGTHS

AVAILABLE UPON REQUEST. UL RECOGNIZED WIRE TO 150C AND 600V. SEE TYPE X391T FOR
TERMINAL VERSION, OR CONSULT FACTORY FOR OTHER OPTIONS.

DIMENSIONS:

AS SPECIFIED IN TABLES.

ELECTRICAL CHARACTERISTICS

CAPACITANCE:

AS SPECIFIED IN TABLES ± REQUESTED TOLERANCE WHEN MEASURED AT OR

REFERRED TO 120 ± 5 HZ AND 25 ± 5 °C. OTHER CAPACITANCE VALUES ARE AVAILABLE UPON
REQUEST.

TOLERANCE:

±3%, ±5%, ±6%, AND ±10% AVAILABLE. OTHER TOLERANCES ARE AVAILABLE UPON

REQUEST.

DISSIPATION FACTOR:

SHALL NOT BE GREATER THAN 0.1% WHEN MEASURED AT OR REFERRED TO

120 ± 5 HZ AND 25 ± 5 °C.

DIELECTRIC STRENGTH:

LEAD TO LEAD - 180% OF RATED AC VOLTAGE OR DC EQUIVALENT FOR 1 –3

SECONDS AT 25 ± 5 °C. TERMINAL TO CASE (T-C) TEST VOLTAGE IS 3000VAC FOR 1-3 SECONDS.

RATED VOLTAGE:

240VAC, 280VAC, 330VAC, AND 400VAC AVAILABLE. ALL RATINGS ARE FOR 50/60

HZ OPERATION ONLY. FOR OTHER VOLTAGE RATINGS CONSULT FACTORY.

TEMPERATURE:

-40 °C TO +100 °C MAXIMUM, AT FULL RATED VOLTAGE.

100 °C MAXIMUM STORAGE TEMPERATURE
LOWER OPERATING TEMPERATURE WILL SIGNIFICANTLY IMPROVE LIFE OF CAPACITOR.

ADDITIONAL INFORMATION

ORDERING INFORMATION:

ALL ASC CAPACITORS ARE ORDERED BY "FAMILY CAP-TOL-VOLT"

DESIGNATION. (I.E. TO ORDER AN X391L 20.0µF, ±10%, 400VAC CAPACITOR, REQUEST PART NUMBER
"X391L 20-10-400")

SEE ALSO:

"GENERAL INFORMATION - POLYPROPYLENE CAPACITORS" DOCUMENT FOR ADDITIONAL

PHYSICAL, ELECTRICAL, AND PERFORMANCE CHARACTERISTICS NOT MENTIONED IN THIS FILE.

AGENCY APPROVALS:

UL CONSTRUCTION ONLY FILE # E190772

WARNING:

INFORMATION ON THIS FILE IS SUBJECT TO CHANGE WITHOUT NOTICE AT ASC'S

DISCRETION.

*** WARNING, THIS PRODUCT IS NOT PROTECTED, IT IS THE USER RESPONSIBILITY

TO PROVIDE CIRCUIT PROTECTION. FAILURE TO DO SO COULD RESULT IN FIRE***

METALLIZED POLYPROPYLENE
DRY CAPS FOR HID LIGHTING
