Voltage Controlled Oscillators

|

 Phase-Locked Loops

|

 40 MHz - 15 GHz

ZComm-Product-Selection-Guide-html.html
background image

Part Number

Low

Freq

(MHz)

High Freq

(MHz)

Vtune

(Vdc)

Kvco

(MHz/V)

(typ)

Output

Power

(dBm)

PN @10kHz

(dBc/Hz)

(typ)

2nd Harm

(dBc)(typ)

Vcc

(Vdc)

Icc (mA)

(typ)

Pushing

(MHz/V)

(max)

Pulling

(MHz)

(max)

Size (Inches)

Package

CLV0600A-LF

530

670

1 - 4.5

52

-2.5 to 5.5

-109

-15

5

24

<2

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV0625E-LF

575

675

0.5 - 4.5

43

-4 to 4

-111

-8

5

25

<2

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV0700E-LF

680

720

0.5 - 4.5

35

0 to 5

-109

-10

5

18

<2

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV0798A-LF

730

920

1 - 15

28

-2 to 6.5

-108

-15

5

19

<2

<1

0.5 x 0.5 x 0.13

MINI-16-L

CLV0750E-LF

750

830

0.5 - 4.5

31

1.5 to 5.5

-110

-14

5

18

<1

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV0835E-LF

800

835

0.5 - 4.5

25

-1 to 5

-111

-17

5

21

<1

<0.2

0.5 x 0.5 x 0.13

MINI-14S-L

CLV0975B-LF

820

1170

0.5 - 15

31

-3 to 3.5

-109

-12

5

20

<2

<0.5

0.5 x 0.5 x 0.22

MINI-14S

CLV1075A-LF

830

1300

0.5 - 17

35

0 to 8

-105

-18

5

26

<4

<2

0.5 x 0.5 x 0.22

MINI-14S

CLV1025E-LF

865

1180

1 - 14

30

1 to 10

-107

-12

5

24

<2

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV0894A-LF

868

920

0.5 - 4.5

19

0 to 6

-113

-15

5

25

<1

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV0890A-LF

890

930

0.5 - 4.5

25

-3.5 to 1

-111

-20

5

20

<0.6

<0.2

0.5 x 0.5 x 0.22

MINI-14S

CLV0925E-LF

896

959

0.3 - 4.7

20

-7 to -3

-111

-24

5

12

<1

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV1000B-LF

900

1100

0.5 - 4.5

60

1 to 10

-104

-20

5

20

<4

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV0989A-LF

939

1039

0.5 - 4.5

29

-2 to 3

-109

-15

5

25

<3

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV1186A-LF

945

1427

0.5 - 24

24

2 to 8

-104

-15

8

30

<2

<2

0.5 x 0.5 x 0.13

MINI-14S-L

CLV0986E-LF

971

1002

0.5 - 4.5

18

-2 to 3

-113

-20

5

20

<1

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV1015E-LF

987

1032

0.6 - 5

21

-7 to -1

-109

-36

4.5

15

<2

<2

0.5 x 0.5 x 0.22

MINI-14S

CLV1030E-LF

990

1070

1 - 4.5

33

1 to 10

-106

-15

5

25

<3

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV1100E-LF

1035

1180

1 - 10

25

0 to 8

-107

-15

5

23

<2

<2

0.5 x 0.5 x 0.22

MINI-14S

CLV1150E-LF

1100

1200

0.3 - 4.7

39

0 to 4

-109

-20

5

22

<1

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV1225A-LF

1180

1270

0.5 - 4.5

37

-1 to 6

-109

-25

5

26

<1

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV1295A-LF

1235

1355

0.5 - 4.5

68

3 to 7

-105

-15

5

26

<4

<2

0.5 x 0.5 x 0.22

MINI-14S

CLV1310A-LF

1260

1370

0.5 - 4.75

40

2 to 7

-107

-11

5

25

<0.5

<1.5

0.5 x 0.5 x 0.13

MINI-14S-L

CLV1350E-LF

1295

1385

0.5 - 4.5

36

-3 to 3

-107

-12

5

21

<1

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV1385E-LF

1370

1400

0.5 - 4.5

21

1 to 6.5

-109

-15

5

18

<1

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV1440E-LF

1400

1486

0.5 - 4.5

33

-3 to 3

-107

-15

5

23

<1

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV1625B-LF

1445

1820

2 - 25

23

-2 to 3

-105

-22

5

25

<2

<1

0.5 x 0.5 x 0.13

MINI-16-L

CLV1585E-LF

1487

1587

0.25 - 4.5

36

2 to 7

-108

-17

5

24

<2

<3

0.5 x 0.5 x 0.13

MINI-14S-L

CLV1525E-LF

1500

1550

0.3 - 4.7

25

-2 to 3

-108

-20

5

25

<1

<1

0.5 x 0.5 x 0.22

MINI-14S

CLV1635A-LF

1600

1670

0.5 - 4.5

33

0 to 6

-108

-25

5

22

<2

<1

0.5 x 0.5 x 0.13

MINI-14S-L

CLV1670A-LF

1640

1700

0.5 - 4.5

30

0 to 5

-111

-21

5

23

<1.5

<1

0.5 x 0.5 x 0.13

MINI-16-L

CLV1750A-LF

1690

1810

0.5 - 4.5

50

3 to 7

-104

-15

5

27

<4

<2

0.5 x 0.5 x 0.22

MINI-14S

Part Number

Low

Freq

(MHz)

High Freq

(MHz)

Vtune

(Vdc)

Kvco

(MHz/V)

(typ)

Output

Power

(dBm)

PN @10kHz

(dBc/Hz)

(typ)

2nd Harm

(dBc)(typ)

Vcc

(Vdc)

Icc (mA)

(typ)

Pushing

(MHz/V)

(max)

Pulling

(MHz)

(max)

Size (Inches)

Package

TRO1350A-LF

1350

1350

0.5 - 4.5

5

0 to 6

-117

-25

5

25

<1

<1

0.375 x 0.375 x 0.12

375

TRO1790A-LF

1790

1790

0.5 - 4.5

5

1 to 7

-118

-12

5

25

<1

<1

0.375 x 0.375 x 0.12

375

TRO1800A-LF

1800

1800

0.5 - 4.5

4

1 to 7

-117

-10

5

25

<1

<1

0.375 x 0.375 x 0.12

375

TRO2000A-LF

2000

2000

0.5 - 4.5

5

5 to 8

-117

-17

5

28

<1

<1

0.375 x 0.375 x 0.12

375

TRO2400A-LF

2400

2400

0.5 - 4.5

4

2 to 8

-113

-20

5

25

<1

<2

0.375 x 0.375 x 0.12

375

LF Suffix = Pb-Free RoHS compliant. All specifications are subject to change without notice. Visit our web site at www.zcomm.com for additional parts and specifications.

2

CLV Series VCOs



|



400 MHz - 4 GHz

Wide Frequency Range

•

 Low Phase Noise

•

 Low Harmonics

The CLV series VCOs utilize a microstrip topology that is based on a patented high-Q distributed resonator design which delivers low phase
noise and linear tuning spanning over a wide range of frequency bands covering 400 MHz to 4 GHz. They exhibit excellent tuning linearity and
superior harmonic suptpression making them the ideal choice for test equipment and satellite communication applications.

TRO Series VCOs



|



1300 MHz - 2400 MHz

Exceptional Phase Noise

•

 Small Size

•

 Low Power Consumption

The TRO series features the latest enhancement in new VCO development. This series utilizes ceramic resonator topology to deliver ultra-low
phase noise performance, but its compact size is what distinguishes itself from other ceramic resonator designs and sets a new standard. The
TRO provides neary a 45% and 70% reduction in overall area and volume size, respectively, in comparison to other CRO models. This series is
currently available in the range of 1300 to 2400 MHz and offers spectral purity that is unmatched in a size measuring 0.375” x 0.375” x 0.12”.
