Part No.

Page

1 of 2

CIR08T9-12W-XIW-101WF

23105 Kashiwa Court, Torrance, CA 90505
Phone:  (800) 579-4875 or (310) 534-1505  Fax: (310) 534-1424
E-mail:  webmaster@ledtronics.com
Website:  http://www.ledtronics.com

DWG NO. CMMS1376

REVISION LTR: A
ECR#: 100214-GP01

10-03-14

10-06-14

LD

MFG:

100~277Vac, G10Q Socket, Warm White, 3000K

Angle of illumination: 120°

LED T9 Tube Light, 9” OD, Frosted, 12W

CIR08T9-12W-XIW-101WF

10-06-14

RD

QA:

R&D:

10-06-14

LUV

DWG BY:

08-28-14

USL / GP

Part No.

Page

2 of 2

23105 Kashiwa Court, Torrance, CA 90505
Phone:  (800) 579-4875 or (310) 534-1505  Fax: (310) 534-1424
E-mail:  webmaster@ledtronics.com
Website:  http://www.ledtronics.com

DWG NO. CMMS1376

CIR08T9-12W-XIW-101WF

1. All Dimensions are in Inches [Millimeters].

Notes:

○

Electro-Optical Characteristics

Input Voltage (typ)

100~277Vac

Tested @ (Voltage)

120Vac

Current Consumption

0.100 A

Power Consumption

12W

Efficacy: (Lm/W)

100

Lumens

1200 lm

Color

Warm White

Max Ft-Cd

320 cd

Power Factor

0.95

CRI (Ra)

80

CCT

3000K~3200K

R9

12.3

Angle of illumination

120°

○

Features

Operating Temperature

-10°C to +45°C

Storage Temperature

-20°C to +65°C

35°C

Heatsink Temperature

Weight

0.45 lbs.

Polycarbonate, White

Base Material

Dimmable

No

Protection Rating

IP20

LED LM80 Report

-

LM79 Report

-

Lens Material

Polycarbonate, Frosted White

Warranty

5 Years

Life Span

40,000 hrs.

  Ø6.56
[Ø166.6]

Ø8.86
[Ø225]

 1.20
 [30.5]

Top View

COMPLIANT

Side View

G10Q-F34 Included
