USTF75B30 Series
Size:
2.98 in sq. x 1.18 in. thk
(75.7mm sq. x 30mm thk.)
Airflow:
9.0 - 11.3 CFM
Acoustical Noise:
32 - 38 dB (A)
MATERIAL:
Frame - Black PBT (UL 94V-0)
Bearings - Ball
Impeller - Black PBT (UL 94V-0)
WEIGHT:
3.17 oz. (90g)
TERMINATION:
Lead Wires (UL 1007, AWG24)
OPERATION TEMPERATURE:
-10
0
to +70
0
C
INSULATION RESISTANCE:
10 megohms min @ 500 VDC
DIELECTRIC STRENGTH:
500 VAC for 1 min.
INSULATION:
Class A
SAFETY:
Impedance & Polarity Protected
SAFETY APPROVALS:
UL, CSA & VDE
OPERATING VOLTAGE:
12 VDC (10 to 13.8) - 24 VDC (14 TO 27.6)
SPECIFICATIONS:
(All values are typical)
PERFORMANCE CURVES:
(Obtained with test chamber and methods in accordance with AMCA Std. 210-74)
