THINNERS & SOLVENTS

Paint Thinner

All purpose mineral spirit type thinner and

solvent for paint and varnish base products.

Part No. 10-6702

2 fl. oz. Bottle

N.S.N. 8010-00-054-1521

Polystyrene Q-Dope

Thinner

For thinning polystyrene base coil dopes and

cements. Can also be used for cementing

polystyrene parts.

Part No. 10-4102

2 fl. oz. Bottle

N.S.N. 8010-00-063-1376
N.S.N. 8040-00-902-1159

Radio-TV Cement

Solvent

Fast acting solvent formulated for use in

speaker repair. Dissolves cement on speaker

cones, spiders, frames, voice-coils. May also

be used as a thinner for all lacquer type

cements.

Part No. 10-312

2 fl. oz. Bottle

Part No. 10-320

16 fl. oz. Bottle

N.S.N. 8010-00-775-5893

Part No. 10-321

1 gal. Can

Part No. 10-321

4 gal. Pack

Print Kote Solvent

A solvent to remove silicone and other

types of protective coatings from PC boards.

Required when modifying PC boards or

replacing components where the protective

coating interferes with the desoldering and

resoldering operation.

Part No. 22-209

2 fl. oz. Bottle

N.S.N. 6810-00-711-2185

COATINGS

Silver Print II

(Conductive Paint)

For PC repair or add-on circuit traces. Pure

silver in acrylic lacquer based carrier may

be brushed on for either conductors or

shielding. Connections have equal or better

conductivity than copper (0.1 ohms per

square inch).

Part No. 22-023

1/2 troy oz. Bottle

Part No. 22-024

1 troy oz. Bottle

Red Insulating Varnish

Alkyd-based compound, especially resistant

to environmental extremes including oils,

water and most acids and alkalis. Retains its

high dielectric strength even if wet and is,

therefore, especially adaptable to the

insulation of electrical and electronic

devices or components which may be

operated in a very humid climate and up to

250°F (121°C). For general insulation of

coils, transformers, motor windings and for

all-around protection against oxidation and

atmospheric attacks.

Part No. 10-9002-A

2 fl. oz. Bottle w/Brush

N.S.N. 5970-00-901-5331

Part No. 10-9008-A

8 fl. oz. Bottle

Print Kote Conformal

Coating

The ultimate coating for PC boards provides

a protective shield to resist environmental

contaminants. Prevents arcing and shorting.

Air dry 15 to 30 minutes. May be baked at

200°C for 30-60 minutes for extreme high

temperature applications.

Part No. 22-203

2 fl. oz. Bottle

N.S.N. 8010-00-711-2173

1,400 V/mil

3,000 V/mil

4 gal. Pack

-4G

CHEMICALS

For the latest information–www.gcelectronics.com

All quantities are single; BU’s are packages of 10 Unless otherwise noted.

Chem

CHEMICAL SPECIFICATION MATRIX (Cont.)

Printed Circuit Products Specifications

HMIS

Flammability

Specific

Shelf Life

DOT

Part No.

MSDS

Description

Contents

Base

Color

Rating

Gravity

Months*

Shipping

22-225

-A

320

208

Positive Type

2 fl. Oz

Sodium

Milky White

1.08

UN 1824

ORM-D

22-226

Developer

6 fl. Oz

Hydroxide

Concentrate

22-237

306

PC Board

6 fl.oz

Ferric Chloride

& Water §

Dark

1.42

UN 2582

ORM-D

22-238

Etching Solution

32 fl oz

§ pH Level = 1.57

Brown

22-239

1 gal.

22-240

104

Stripping

2 fl. Oz

MEK &

Clear

0.84

UN 1993

ORM-D

Solution

Xylene

22-244

131

Etch Resist

2 fl. Oz

Hydrocarbon

Black

0.92

UN 1263

ORM-D

Lacquer

Solvent

Silicone Sealants Specifications

HMIS

Specific

Flammability

Specific

Tensile

Dielectric

Shelf Life

Dot

Part No.

MSDS

Description Contents

Base

Color

Rating

Gravity

Consistency

Strength

Temperature

Months*

Shipping

10-150

149

Silicone Rubber

3 fl.oz

Vulcanized Clear

1.03

Non-Slump

220 psi

500 v/mil

-80°F to 400°F

Not

Adhesive/Sealant

Silicone

Paste

Regulated

19-155

201

Electronic Grade

3 fl.oz Vulcanized

Clear

1.04

Non-Slump

225-275 psi

18 KV/mm

-70°F to 400°F

Not

Silicone

Paste

Regulated

Sealant/Adhesive

19-158

275

Electronic Grade

10.2 fl oz

Vulcanized

White

1.04

Non-Slump

225-275 psi

18 KV/mm

-70°F to 400°F

Not

Silicone

Paste

Regulated

Sealant/Adhesive

19-159

2.8 fl oz

EL-615

202

Silicone Caulk

10.2 fl oz

Vulcanized

Clear

1.03

Non-Slump

220 psi

25 KV/mm

-70°F to 400°F

Not

Tube

Silicone

Paste

Regulated

Coating Specifications

HMIS

Flammability

Specific

Drying

Dielectric

Useful Temp.

Suggested

Shelf Life

DOT

Contents

Base

Color

Rating

Gravity

Time

Strength

Range

Solvent

Months*

Shipping

22-023

278

Silver Print II 1/2 troy oz.

Acrylic

Silver

Dry 20-30 min.

Butyl Acetate

UN 1307

ORM-D

22-024

1 troy oz.

Force Dry 30 min

@ 80ºC

10-9002

307

Red

2 fl. oz.

Alkyd-Resin

Red

1.100

8-24 hours Air Dry

@ 77°F

40 – 55 sec. #3

EZ Zahn Cup @ 77ºF

Up to 93ºC

Use Xylene

or 22-209

UN 1263

ORM-D

10-9008

Insulation

8 fl. oz.

Based Enamel

(200ºF)

Varnish

3,000 v/Mil

22-203

138

Print Kote

2 fl. oz.

High Polymer

Clear

0.880

Air Dry

850 cp @ 25ºC

1,400 v/Mil

-65ºC to 200ºC

Use

UN 1993

ORM-D

Conformal

Silicone Resin

15-30 mins.

(-85ºF to 392ºF)

22-209

Coating

10-1762

135

Insulating 2 fl. oz. Synthetic Resin Black

0.930

4 hrs.

7,000 - 22,000 cps

1,400 v/Mil

-30ºF to +200ºF

UN 1139

ORM-D

10-1766

Coating

16 fl. oz.

in Solvent

Use Toluene

or 22-209

10-8665

159

Acrylic

11 oz. aerosol Polymeric

Clear

0.740

10 mins

250 CP @ 25ºC

3,800 v/Mil

Up to 190ºC

Use

Toluene

ORM-D

209

Corona Dope

2 fl. oz.

Cellulose

Black

0.900

30-60 mins.

220 CP @ 25ºC

Up to 340ºF

UN 1263

ORM-D

-4702

10-312 or Lacquer

Thinner

10-5002

137

Red-X

2 fl. oz.

Thixotopic

Red

1.120

2 hrs.

200-400

CP @ 25ºC

2,000 v/Mil

Up to 105ºC

Xylene

UN 1263

ORM-D

Corona Dope

Polyester Enamel

(220˚ F)

10-3702

101

Q Dope

2 fl. oz.

Styrene

Milky

0.878 ± 0.040 80% Strength:

72 Hr.

Use

ORM-D

10-3704

4 fl. oz.

White

10-4102

10-3709

1 gal.

UN 1133

*Note:

Shelf Life is determined by the Date Of Manufacture

(DOM) located on the product. If a product has a shelf life of 12 months, a closed container is good for

one year

past the DOM.

Part No.

MSDS

Description

-70°F to 400°F

N/A

0 cps

CHEMICALS

Phone (815)316-9080•Fax (815)316-9081

All quantities are single; BU’s are packages of 10 Unless otherwise noted.

Chem

COATINGS (Cont.)

Insulating Coating

Heavy-bodied, black insulating coating which

replaces insulating tape in applications where

wrap-around tape could not readily be

applied. This compound dries quickly to a

strong pliable finish that will not crack, peel or

chip. It is water and oil proof and may be used

outdoors to insulate any electrical terminal,

connection or wire splice. Excellent for

providing insulation on handles, etc. Voltage

rating 1400v/mil (min.)

Part No. 10-1762

2 fl. oz. Bottle with Brush

Part No. 10-1766

16 fl. oz. Bottle

Corona Dope

This lacquer has excellent dielectric, arc

and corona resisting properties, and

protects surfaces against moisture.

Achieved with a quick drying, black

lacquer insulating coating, based on a

cellulose resin. Temperature range: to

325°F (163°C). This lacquer is used to coat

flybacks, coils, transformers to improve the

insulation and weather resistant properties

of wires. Dielectric Strength: 3,800

Volts/Mil Min.

Part No. 10-4702

2 fl. oz. Bottle with Brush

N.S.N. 8030-00-778-4278

N.S.N. 5970-00-063-0685

Q Dope

Solution of pure polystyrene in solvents.

Dries fast and leaves a clear, protective coat-

ing on coils and transformers, with no or

minimal effect on inductive values. May also

be used as a cement for molded or fabri-

cated items made of polystyrene.

Part No. 10-3702

2 fl. oz. Bottle with Brush

N.S.N. 8010-00-868-3866

N.S.N. 5970-00-044-6790

N.S.N. 5970-00-982-3909

Part No. 10-3704

4 fl. oz. Bottle with Brush

N.S.N. 5970-01-047-9265

N.S.N. 8040-00-598-9748

Part No. 10-3709

1 gal. Can

N.S.N. 8030-00-182-6416

Red-X Corona Dope

Thixotropic polyester-base red enamel that

will not drip or sag, has excellent adhesion

and is oil and waterproof. Temperature

range: to 220°F (104°C). An excellent

insulator, corona and spark preventive

coating. For moisture-proofing and

insulation of high voltage coils and other

high voltage components, especially in high

humidity problem areas. Also recommended

for rotor and field coils in motors, to coat

transformers, etc. Dielectric strength: 1,700

Volts/Mil Min., dielectric constant: 3.7.

Part No. 10-5002

2 fl. oz. Bottle with Brush

N.S.N. 8040-00-779-2866

Acrylic Plastic

Transparent (glass-like) lacquer. Seals,

protects, insulates and tarnish-proofs any

object to which it is applied. This coating

has high dielectric strength and resists

moisture, caustic solutions and alcohols.

Used to coat electronic component and

connections as well as metal or art objects

(to protect against tarnish and corrosion).

Part No. 10-8665

11 oz. Aerosol
