Description
0444173951 Fair-Rite Ferrite Clamp On Cores BB Freq 43&44 Mat 187Ohm @250MHz Round
Specifications
Manufacturer: Fair-Rite
Product Category: Ferrite Clamp On Cores
RoHS: Details
Shape: Round
Product Type: Round Cable Core
Inside Diameter: 5.1 mm
Outside Length: 25 mm
Outside Width: 12.8 mm
Outside Height: 5.6 mm
Packaging: Bulk
Core Material: 44
Operating Temperature Range: – 55 C to + 125 C
Brand: Fair-Rite
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: – 55 C
NumOfPackaging: 1
Factory Pack Quantity: 504
Tradename: SNAP-ITS
Unit Weight: 0.229281 oz
Round cable snap-its can easily accommodate round cables or bundled wires with diameters from 2.5 mm (.100”) to 25.4 mm (1.000”). These assemblies are available in four ferrite material classes to suppress differential or common-mode conducted EMI from 1 MHz into the GHz region. The polypropylene cases are meeting the RoHS restrictions of hazardous substances and have a flammability rating of UL94 V-0.
Manufacturer Part Number: 444173951
Fair-Rite
