Description
10SR-35K-J ATE Electronics ixed Resistor 35kohm 5% 13W 30ppm/C
Specifications
Resistance 35 kohm
Power Rating 13W
Tolerance 5%
Technology Wirewound
Series 10SR
Case Style Ceramic
Temperature Coefficient 30ppm/C
Dimensions 9.5 (Dia.) x 50mm
Length 50mm
Diameter 9.5mm
Maximum Temperature Coefficient +30ppm/C
Minimum Temperature Coefficient -30ppm/C
Maximum Operating Temperature +350C
Minimum Operating Temperature -55C
The SR series of capacitor balancing resistors from ATE Electronics offers 5% tolerance as standard. These resistors are available in E24 Series ohmic values. Featuring a dielectric strength of 1000 V ac, these balancing resistors can be used to minimise voltage imbalance from capacitors connected in a series. SR capacitor balancing resistors offer temperature coefficient values of 100 to 30 ppm from 10 ? upwards. SR series resistors have been vibration tested to IEC 60571-1 standards. SR10 resistors have a 31.8mm centre and SR7 resistors have a 22.2mm centre. The fixing centre dimensions cover most of the screw terminal electrolytic capacitor offering.
Manufacturer Part Number: 10SR-35K-J
ATE Electronics
