11745T115 Flexible Metal Trim Cushioned Parallel Teeth Made of stainless steel, this trim has excellent corrosion resistance and good chemical resistance, making it the best choice for harsh and outdoor environments. It meets UL 94 V-0 flammability standards, 3/64″ x 3/16″ Inside 5′ Long RoHS
Trim with parallel teeth has a stronger grip than trim with alternating teeth, so it’s better for edges with round and irregular profiles. It also handles twists and turns, such as on the edge of a spiral conveyor.
Cushioning on the top provides added protection from impact. This nylon-coated stainless steel trim combines strength with flexibility for a snug hold. It can also protect wire, cable, and hose. Push onto your edge or object to install.
Tooth Style: Parallel
Mount Type: Push On
Profile: U
Material: Nylon Coated Stainless Steel
Inside:
Width (A): 3/64″
Height (B): 3/16″
Outside:
Width (C): 3/16″
Height (D): 15/64″
Flexibility: Flexible
Temperature Range: -40 to 180F
For Use Outdoors: Yes
Specifications Met: MIL-STD-202, UL 94 V-0
Color: Black
Length: 5 ft.
RoHS: RoHS 3 (2015/863/EU) Compliant
Manufacturer: Electronic Components
MFG Part #: 11745T115
