Description
12-22/G6R8C-A30/2C Everlight Bi-Color LED 650nm/575nm Yellow / Green / Red 90/57 mcd 2.4/2.4V Surface Mount LED T/R RoHS
The 12-22 SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained.Besides, lightweight makes them ideal for miniature applications etc.
Category Chip LED
Color Red/Yellow Green
Dominant Wavelength 639/573 nm
Intensity 57(Max)|90(Max) mcd
LED Material AlGaInP
Lens Dimensions 2x1x0.9 mm
Lens Shape Type Rectangular
Max Processing Temp 260
Maximum Forward Current 25 mA
Maximum Forward Voltage per Color 2.4 V
Maximum Power Dissipation 60 mW
Mounting Surface Mount
Mounting Orientation Top Mount
Number of LEDs 2
Operating Temperature -40 to 85 C
Peak Wavelength 650/575 nm
Pin Count 3
Product Dimensions 3 x 1 mm
Reverse Voltage 5 V
Supplier Package Chip LED
Type Bi-Color
Viewing Angle 120
Manufacturer: Everlight
MFG Part #: 12-22/G6R8C-A30/2C
