Description
14311617106000 Harting Terminal Block 16 Position 0.200″ (5.08mm) 180° 1230 AWG 0.22.5mm² Screwless Spring Cage, Tension Clamp 12A 300V Mating Flange, Push Button Actuated, Retention Latches (NonWire Side) Free Hanging (InLine) Green
Type: Plug, Female Sockets
Series: Har-flexicon®
Current: 12A
Voltage: 300V
Pitch: 0.200″ (5.08mm)
Number of Position: 16
Positions Per Level: 16
Termination Style: Screwless Spring Cage, Tension Clamp
Mounting Type: Free Hanging (InLine)
Operating Temperature: -40°C ~ 110°C
Contact Mating Finish: Tin
