Description
1627A B&K Precision Power Supply Bench (AC to DC) 120VAC 220WLED 0 ~ 30VDC 0 ~ 3A Regulated. The 1620A series are rugged, compact, low-cost DC regulated power supplies providing clean and stable DC power.
Features:
● Continuously monitor voltage and current output on two analog meters
● Connect two supplies in parallel to double the current output
● Connect two supplies in series to double the voltage output
● New compact style
● Reliable, Durable
● Operate continuously at full load without overheating
● Fully overload protected
● Coarse and fine voltage controls
● Great regulation
● Very low ripple
● Constant voltage or constant current operation
Specs
Brand: B&K Precision
Voltage Range Selector: 30-49.9
Output Voltage: 30 V
Current Range Selector: 2.5-4.9
Output Current: 3 A
Power Range Selector: 200-499
Power Rating: 220 W
Mounting Type: Bench Top
Input Voltage: 120 VAC
Series: Basic Series
Display: LED
Interface: None
Number of Outputs: Single Output
Programmable: No
Special Features: Constant Current, Constant Voltage
Number of Outputs: 1
Voltage Output: 0 ~ 30VDC
Current Output: 0 ~ 3A
Size / Dimension: 10.630″ L x 4.528″ W x 8.071″ H (270.00mm x 115.00mm x 205.00mm)
Manufacturer: B&K Precision
Datasheet: 1620A_datasheet.pdf
