Description
1711A B&K Precision Power Supply Bench (AC to DC) 120VAC Analog (2) 0 ~ 60VDC 0 ~ 2A Constant Current and Constant Voltage Indicators. The B&K Precision 1711A Single Output DC Power Supply enables you to continously monitor voltage and current output on two analog meters. These bench power supplies have coarse and fine voltage control knobs along with a low and high range current control with dual analog displays to continuously monitor both output current and voltage.
Replaced by: 1715A
Continuously monitor voltage and current output on two analog meters
Connect two supplies in parallel to double the current output
Connect two supplies in series to double the voltage output
Reliable, Durable
Operate continuously at full load without overheating
Fully overload protected
Coarse and fine voltage controls
Excellent regulation
Very low ripple
Constant voltage or constant current operation
Specs
Product Category: Power Supplies – Bench Top
Product: DC Power Supplies
Input Voltage: 120 VAC, 220 VAC, 230 VAC, 240 VAC
Number of Outputs: 1 Output
Output Voltage-Channel 1: 0 VDC to 60 VDC
Output Current-Channel 1: 0 A to 2 A
Output Power: 210 W
Display Type: Dual Analog
Brand: B&K Precision
Cable Type: North American Power Cord Included
Height: 5.5 in
Length: 1.042 ft
Product Type: Bench Top Power Supplies
Subcategory: Power Supplies
Width: 5.5 in
Unit Weight: 12 lbs
Number of Outputs: 1
Voltage Output: 0 ~ 60VDC
Current Output: 0 ~ 2A
Size / Dimension: 12.500″ L x 5.500″ W x 6.200″ H (317.50mm x 139.70mm x 157.48mm)
Manufacturer: B&K Precision
