Description
1715A B&K Precision Power Supply Bench (AC to DC) 120VAC LED 0 ~ 60VDC 0 ~ 2A Constant Current and Constant Voltage Indicators. Provides exceptional accuracy with dual analog displays and coarse and fine voltage and current controls, this DC power supply features an output voltage of 0 to 60 V and an output current of 0 to 2 A. In addition, it operates continuously at full load without overheating and is fully overload protected.
Continuously monitor voltage and current output on two 4 digit LED displays
Connect two supplies in parallel to double the current output
Connect two supplies in series to double the voltage output
Reliable, Durable
Operate continuously at full load without overheating
Fully overload protected
Coarse and fine voltage controls
Excellent regulation
Very low ripple
Constant voltage or constant current operation
cUL certified
specs
Brand: B&K Precision
Voltage Range Selector: 50-99.9
Output Voltage: 60 V
Current Range Selector: 0-2.49
Output Current: 2 A
Power Range Selector: 200-499
Power Rating: 210 W
Mounting Type: Bench Top
Input Voltage: 120 VAC
Series: 1700A Series
Display: Digital
Interface: None
Number of Outputs: Single Output
Special Features: Constant Current, Constant Voltage
Number of Outputs: 1
Voltage Output: 0 ~ 60VDC
Current Output: 0 ~ 2A
Size / Dimension: 12.500″ L x 5.500″ W x 6.200″ H (317.50mm x 139.70mm x 157.48mm)
Manufacturer: B&K Precision
Datasheet: 17xxA_datasheet.pdf
