Description
1733606 Phoenix Contact PCB terminal block 5 connection Position, nominal current: 17.5 A – rated voltage (III/2): 400 V – nominal cross section: 1.5 mm2 – pitch: 5.08 mm method: Screw connection with tension sleeve – mounting: Wave soldering – conductor/PCB connection direction: 55 – color: green – Pin layout: Linear pinning – Solder pin [P]: 3.5 mm RoHS
Specifications
Manufacturer: Phoenix Contact
Product Category: Fixed Terminal Blocks
Number of Positions: 5 Position
Pitch: 5.08 mm
Connection Method: Screw
Current Rating: 17.5 A
Voltage Rating: 250 V
Mounting Style: PCB Mount
Mounting Angle: 35 deg
Series: SMKDSP
Brand: Phoenix Contact
Contact Material: Copper
Flammability Rating: UL 94 V-0
Height: 18.8 mm
Housing Material: Polyamide (PA)
Length: 13.4 mm
Product: Fixed Terminal Blocks
Product Type: Fixed Terminal Blocks
Subcategory: Terminal Blocks
Termination Style: Through Hole
Tradename: COMBICON Control
Wire Gauge Max: 14 AWG
Wire Gauge Min: 26 AWG
Wire Orientation: 35 Deg
Part # Aliases: SMKDSP_1,5/_5-5,08 SMKDSP155508
Unit Weight: 0.251362 oz
Manufacturer: Phoenix Contact
MFG Part #: 1733606
