Description
1794 B&K Precision Power Supply Rack Mount (AC to DC) 115VAC LED 0 ~ 32VDC 0 ~ 30A Rack Mount. The model 1794 is a cost effective, high power, regulated DC power supply with an output rating of (0 to 32V, 0 to 30A). It is a linear high current DC power supply suitable for bench operation or standard 19″ rack operation. This linear power supply is a high power workhorse that will easily deliver clean power to your high current circuits.
The model 1794 is a cost effective, high power, regulated DC power supply with an output rating of (0 to 32V, 0 to 30A). It is a linear high current DC power supply suitable for bench operation or standard 19″ rack operation. This linear power supply is a high power workhorse that will easily deliver clean power to your high current circuits.
Constant Voltage/Constant Current Operation
Remote Programming Facility
Facility for Presetting the Output Voltage and Max. Load Current Limits
Separate DC Output ON/OFF Switch
Remote Sensing Facility
High Stability and Close Regulation ±0.01%
Meet CE Specifications
The BK Precision 1794 is a high current Linear Regulated DC power supply with adjustable output power ranging from 0-32V and a maximum current output of 30 A. This linear power supply has one channel/output and is made in the United States. It is designed for precision testing, measurement, and inspection applications in various industrial and business settings. With a focus on quality and reliability, this power supply is ideal for accurately controlling and providing a stable power source for a wide range of experiments and measurements.
Replaced by: XLN3640
Constant Voltage/Constant Current Operation
Remote Programming Facility
Facility for Presetting the Output Voltage and Max.
Load Current Limits
Separate DC Output ON/OFF Switch
Remote Sensing Facility
High Stability and Close Regulation ±0.01%
Meet CE Specifications
Two Year Warranty
Number of Outputs: 1
Voltage Output: 0 ~ 32VDC
Current Output: 0 ~ 30A
Size / Dimension: 15.750″ L x 19.000″ W x 5.250″ H (400.05mm x 482.60mm x 133.35mm)
Manufacturer: B&K Precision
Datasheet: 179x_datasheet.pdf
