Description
1828498 Phoenix Contact Connector Terminal Block PCB connector – nominal current: 8 A – rated voltage (III/2): 160 V – nominal cross section: 1.5 mm2 – number of positions: 2 – pitch: 3.81 mm – connection method: Screw connection with tension sleeve – color: green – contact surface: Tin
Specifications
Manufacturer:Phoenix Contact
Product Category:Pluggable Terminal Blocks
RoHS
Product:Plugs
Number of Positions:2 Position
Pitch:3.81 mm
Connection Method:Screw
Current Rating:8 A
Voltage Rating:160 V
Wire Gauge Min:28 AWG
Wire Gauge Max:16 AWG
Wire Gauge Range:28 AWG to 16 AWG
Series:MCVW
Contact Plating:Tin
Height:19.1 mm
Housing Material:Polyamide (PA)
Length:10.4 mm
Width:18.01 mm
Brand:Phoenix Contact
Contact Material:Copper
Flammability Rating:UL 94 V-0
Product Type:Pluggable Terminal Blocks
Factory Pack Quantity:50
Subcategory:Terminal Blocks
Tradename:COMBICON Control
Part # Aliases:MCVW 1,5/ 2-STF-3,81 MCVW152STF381
Unit Weight:0.085257 oz
Manufacturer:Phoenix Contact
Datasheet:1828498.pdf
