Description
CTS CORP 204-126ST SLIDE DIP SWITCH-5SWITCHES, SPDT, LATCHED,0.1A, 50VDC, SURFACE MOUNT-STRAIGHT
Specifications
Manufacturer: CTS
Product Category: DIP Switches / SIP Switches
RoHS: RoHS Compliant Details
Number of Positions: 6 Position
Switch Type: DIP
Actuator: Slide
Terminal Pitch: 2.54 mm
Contact Form: SPDT
Termination Style: Solder Pad
Mounting: Gull Wing
Brand: CTS Electronic Components
Packaging: Tube
Series: 204
Circuit SPDT
Number of Positions 6
Current Rating 50mA
Voltage Rating 24VDC
Actuator Type Slide (Standard)
Actuator Level Raised
Contact Finish Gold
Height Above Board 0.394″ (10.00mm)
Mounting Type Surface Mount
Termination Style Gull Wing
Pitch 0.100″ (2.54mm), Full
Washable Yes
Features Epoxy Sealed Terminals, Tape Seal
Body Material Plastic
Length 1.086″ (27.58mm)
Operating Temperature -55°C ~ 85°C
Electrical Life 5,000 Cycles
Manufacturer:Electronic Components
Datasheet:204-193.pdf
