Description
2257-06 Neltron Housing Double Rows Connector 6 Position 4.20mm Receptacle RoHS
Type: Wire To Wire Series
Mating Part: 2259-XX
Current rating:9.0A AC / DC
Voltage rating:600V AC / DC
Contact resistance:10m ohm. max.
Insulation resistance:1,000M ohm. min.
Withstand voltage:1,500V AC for one minute
Operating temperature:-40C to +105
Material plating:
1. Insulator: Nylon 66 (UL94V-2)
2. Contact: Brass
3. Plating: Tin Plated
Manufacturer:Neltron
Datasheet:2257-XX-XX.pdf
