Description
52030-0629 Molex FFC & FPC Connector 6 Position 1mm Pitch 6Way Straight Female FPC Conn; ZIF Contact RoHS
This Easy-On range of Molex 52610 and 52030 Series of ZIF FFC connectors will accept FFC cable of a 1mm footprint.
The 52610 series of Straight (Vertical) ZIF FFC connectors are SMT compatible.
The 52030 series of Straight (Vertical) ZIF FFC connectors are Through Hole mount.
The Phosphor Bronze terminals of the 52610-xx33 series SMT Straight (Vertical) ZIF FFC connectors are Silver Tin-Bismuth over Nickel plating with the PCB Retention fitting nail being Tin plated. The housing material of these SMT Straight (Vertical) ZIF FFC 52610-xx33 series connectors is a UL 94V-0 rated Polyamide – Glass filled.
The Phosphor Bronze terminals of the 52610-xx71 series SMT Straight (Vertical) ZIF FFC connectors are Tin-Bismuth over Nickel plated. The housing material of these SMT Straight (Vertical) ZIF FFC 52610-xx71 series connectors is a UL 94V-0 rated Nylon.
The Phosphor Bronze terminals of the 52610-xx72 series SMT Straight (Vertical) ZIF FFC connectors are Gold over Nickel plated on the contact area and Tin plated on the PC Tails. The housing material of these SMT Straight (Vertical) ZIF FFC 52610-xx72 series connectors is a UL 94V-0 rated Nylon.
The Phosphor Bronze terminals of the 52030-xx29 series Through Hole Straight (Vertical) ZIF FFC connectors are Tin-Bismuth over Nickel plated. The housing material of these Through Hole Straight (Vertical) ZIF FFC 52030-xx29 series connectors is a UL 94V-0 rated Nylon.
Specifications
Manufacturer:Molex
Product Category:FFC & FPC Connectors
Product:Board Mount
Number of Positions:6 Position
Pitch:1 mm
Termination Style:Through Hole
Mounting Angle:Vertical
Contact Plating:Tin Bismuth
Current Rating:1 A
Series:52030
Minimum Operating Temperature:- 20 C
Maximum Operating Temperature:+ 80 C
Packaging:Tray
Voltage Rating:50 V
Brand:Molex
Mounting Style:Through Hole
Actuation Type:ZIF
Product Type:FFC & FPC Connectors
Factory Pack Quantity:2500
Subcategory:FFC & FPC Connectors
Part # Aliases:0520300629 520300629
Unit Weight:0.011027 oz
Manufacturer:Molex
Datasheet:Molex/52030-0629.pdf
