Description
74437429203151 Wurth Shielded Drum Core, Wirewound Inductor 150uH 20% 8.4A AEC-Q200 38.85mOhm 100 kHz Surface Mount 2920 Nonstandard
Inductor Type: Drum Core, Wirewound
Shielding: Shielded
Inductance: 150uH
Tolerance: ±20%
Current Rating: 8.4A
Current – Saturation (Isat): 7.8A
DC Resistance (DCR): 38.85mOhm
Frequency Self Resonant: 3.8MHz
Inductance Frequency – Test: 100 kHz
Size / Dimension: 1.102″L x 0.984″W (28.00mm x 25.00mm)
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount Nonstandard 2920
Manufacturer PN: 74437429203151
Manufacturer: Wurth Elektronik
Datasheet: 74437429203151.pdf
