Description
88E6141-A0-NXU2C000 Marvell Ethernet Switch ICs 6-Port Gigabit with 4 EEE GE PHY 2.5G SGMII 1V 72mA 88-pin QFN RoHS
The Marvell Link Street 88E6341 device is single-chip, 6-Port Ethernet Switch with four integrated 10/100/1000Mbps Ethernet transceivers and one high speed SerDes interfaces supporting 2500-BaseX, 1000Base-X, and SGMII. The device also includes an integrated microprocessor with internal memory to enable smart or lightly managed switches without the need of an external CPU.
The high performance switch fabric provides line rate switching on all ports simultaneously while providing advanced switch functionality and QoS. The device includes a TCAM to enable
flexible switch policing, including Access Control Lists (ACLs) and Policy Control Lists (PCLs). The 88E6341 also supports the latest IEEE 802.1 Audio Video Bridging (AVB) identify and reserve the network resources for AVB/TSN traffic streams and
supports precise isochronous streaming capability for reliable and quality audio/video transmission over Ethernet for todays
real-time, high definition information and entertainment options. The AVB protocols enable timing sensitive streams
(such as digital video, audio, or industrial control traffic) to be sent over the Ethernet network with low latency and robust quality of Service guarantees.
6-Port switch for Gateway Applications
4 integrated GE PHYs
1 SerDes/SGMII supporting 2.5Gbps or 1Gbps
1 RGMII/MII/RMII
Features :
Integrated 200MHz Z80 microprocessor
60KByte internal memory
Energy Efficient Ethernet (802.3az)
Wake-on-LAN, Wake-on-Frame support
2K MAC Addresses
Supports latest 802.1 TSN/AVB standards
Sync-E and 1588v2 support
128 Entry TCAM for deep packet inspection
88-pin QFN package (10x10mm)
Manufacturer:Electronic Components
Datasheet:marvell-link-street-88E6341-product.pdf
