Description
9131B B&K Precision Power Supply Bench (AC to DC) 110VAC, 220VAC 375WVFD 0 ~ 30VDC, 0 ~ 30VDC, 0 ~ 5VDC 0 ~ 6A, 0 ~ 6A, 0 ~ 3A Memory, Programmable, RS232 and USB Interface. The 9130B series of power supplies features three linear, programmable outputs. Adjust each output independently or combine in series or parallel to obtain higher output and currents. Operate in tracking mode, with user-defined ratios between channels, to maintain a programmed ratio. Quickly set voltage and current values using the front panel keys and rotary knob.
Specs
Product Category: Power Supplies – Bench Top
Product: DC Power Supplies
Input Voltage: 110 VAC, 220 VAC
Number of Outputs: 3 Output
Output Voltage-Channel 1: 0 VDC to 30 VDC
Output Current-Channel 1: 0 A to 6 A
Output Voltage-Channel 2: 0 VDC to 30 VDC
Output Current-Channel 2: 0 A to 6 A
Output Voltage-Channel 3: 0 VDC to 5 VDC
Output Current-Channel 3: 0 A to 3 A
Output Power: 375 W
Display Type: VFD
AC Supply Voltage: 110 VAC/220 VAC
Brand: B&K Precision
Cable Type: North American Power Cord Included
Height: 3.47 in
Length: 1.438 ft
Product Type: Bench Top Power Supplies
Series: 9130B
Subcategory: Power Supplies
Width: 8.45 in
Unit Weight: 33.069 lbs
Number of Outputs: 3
Voltage Output: 0 ~ 30VDC, 0 ~ 30VDC, 0 ~ 5VDC
Current Output: 0 ~ 6A, 0 ~ 6A, 0 ~ 3A
Size / Dimension: 17.520″ L x 8.445″ W x 3.472″ H (445.00mm x 214.50mm x 88.20mm)
Manufacturer: B&K Precision
Datasheet: 9130B_Series_datasheet.pdf
