Description
9202 B&K Precision Power Supply Bench (AC to DC) 110VAC, 220VAC 360WVFD 0 ~ 60VDC 0 ~ 15A Memory, Programmable, GPIB, RS232, and USB Interface. Unlike conventional supplies with fixed output ratings, this power supply automatically recalculates voltage and current limits for each setting, providing full output power in any Volt/Amp combination within the rated voltage and current limits.
The 9200 Series can replace multiple supplies on your bench or in your rack. Unlike conventional supplies with fixed output ratings, the 9200 Series automatically recalculates voltage and current limits for each setting, providing max output power in any Volt/Amp combination within the rated voltage and current limits.
These supplies provide a numerical keypad for direct entry of voltage and current values along with convenient cursors and a rotary knob to quickly make incremental voltage and current changes. For remote control, the standard USB, RS232, and GPIB interfaces supporting SCPI commands can be used to remotely control the power supplies via a PC. Alternatively, users can control the power supply, execute test sequences or log measurements using the provided PC software application. This software also integrates with Data Dashboard for LabVIEW apps enabling iOS, Android, or Windows 8 compatible tablets or smartphones to remotely monitor select measurement indicators.
These features make the 9200 Series suitable for a wide range of applications including production testing, R&D, electronic field service, and education.
●Multi-ranging operation
●High programming and readback resolution of 1mV / 0.1 mA
●Store and recall up to 72 instrument settings
●Output timer function
●List mode programming
●Standard USB (USBTMC-compliant), RS232, and GPIB interfaces supporting SCPI commands for remote control
●Remote sense
●Thermostatically controlled fan
●Built-in digital voltmeter (DVM)
●Overvoltage/overpower/overtemperature protection, and key-lock function
●NI certified LabVIEW driver and softpanel for remote control, test sequence generation, and datalogging available
●Compact 19″ half-rack form factor allows
Specs
Product Category: Power Supplies – Bench Top
Product: DC Power Supplies
Input Voltage: 110 VAC, 220 VAC
Number of Outputs: 1 Output
Output Voltage-Channel 1: 0 VDC to 60 VDC
Output Current-Channel 1: 0 A to 15 A
Output Power: 360 W
Display Type: VFD
AC Supply Voltage: 110 VAC, 220 VAC
Brand: B&K Precision
Cable Type: North American Power Cord Included
Height: 3.47 in
Length: 13.96 in
Product Type: Bench Top Power Supplies
Series: 9200
Subcategory: Power Supplies
Width: 8.45 in
Unit Weight: 23 lbs
Number of Outputs: 1
Voltage Output: 0 ~ 60VDC
Current Output: 0 ~ 15A
Size / Dimension: 13.960″ L x 8.450″ W x 3.470″ H (354.58mm x 214.63mm x 88.14mm)
Manufacturer: B&K Precision
Datasheet: 9200_Series_datasheet.pdf
