Description
The 97F9121 is a Film Capacitor with quick-connect blade terminations and an oval can case. The GEM III series capacitor is manufactured with high-grade metalized polypropylene film. The metalized electrode is several hundred angstroms thick. The film is wound into capacitor rolls on high-speed and high-precision machines. The winding is extremely tight so that there is not enough space between the layers for corona (localized partial electrical discharges) to occur. The rolls are sprayed on both ends with metal to make the connection to the extremely thin edges of the metalized electrodes. This process is critical to the quality and performance of the capacitors. The rolls are assembled in metal cases, Regal-Beloit’s proprietary dielectric liquid is introduced under vacuum and the capacitor is sealed. This capacitor is designed specifically for the motor run applications where the capacitor is used in conjunction with permanent split capacitor type motors.
30?A Maximum leakage current
60000 hours with 94% survival Operating Life
0.1% Maximum dissipation factor
Applications
Motor Drive & Control
Manufacturer:Genteq
Datasheet:Genteq/185959.pdf
