Description
A4BY4001 Mersen Slow Blow L Fuse 4.001kA 600VAC 300VDC Cylindrical Cartridge Bolt Mount CSA, UL
Mersen A4BY4001 Fuse 4001 Amp, 600 Volts, UL Class L, 4 Second Time Delay, Current Limiting, Physical Size: 6 1/4″ x 10 3/4″, Glass Melamine Body, Mains, Feeders & Circuit Breakers, AC Voltage Rating: 600, DC Voltage Rating: 300, Interrupting Rating: 200,000 AIC @ 600VAC, DC Interrupting Rating: 100,000 AIC, UL Listed, CSA Certified,
Time-delay bolt-on fuses, also called slow-blow fuses, are current protection devices that tolerate brief spikes from short events such as motor starts or equipment startups. They feature tabs or lugs with holes that allow them to securely bolt onto terminals, busbars, and other components.
Product Category: Industrial & Electrical Fuses
Product: Class L Fuses
Current Rating: 4.001 kA
Voltage Rating AC: 600 VAC
Fuse Type: Time Delay / Slow Blow
Voltage Rating DC: 300 VDC
Interrupt Rating: 200 kA
Body Style: Cartridge Blade Fuses
Mounting Style: Holder
Termination Style: Knife Blade
Fuse Size / Group: Class L
Indicator Style: Without Indicator
Brand: Mersen
Diameter: 158.75 mm
Length: 273 mm
Product Type: Industrial Power Fuses
Subcategory: Fuses
MPN: A4BY4001
Manufacturer: Mersen Ferraz Shawmut
Response Time: Slow Blow
Fuse Type: Cartridge
Current Rating: 4.001kA
Voltage Rating: 600VAC
Breaking Voltage: 200kA AC, 100kA DC
Package / Case: Cylindrical, Blade Terminal (Bolt)
Size / Dimension: 6.260″ Dia x 10.748″ L (159.00mm x 273.00mm)
Mounting Type: Bolt Mount
Applications: Electrical, Industrial
