Description
SACE EMAX CIRCUIT-BREAKER E2S-A 1600A UL THREE-POLE FIXED WITH TERMINALS REAR HORIZONTAL OVERCURRENT RELEASE PR121/P-LSI R1600 FITTED WITH: 4 AUXILIARY CONTACT AND C.BREAKER IN POSITION OPEN-CLOSED
Low-Voltage AC Power Circuit Breaker
1600 Amps Frame | 800 A Rating Plug
Auxiliary Switch
SACE Emax
Technical
Current Type:
AC
Electrical Durability:
Ue =< 508 V 10000 cycle
Ue = 508 … 635 V 10000 cycle
30 cycles per hour
Mechanical Durability:
20000 cycle
30 cycles per hour
Number of Poles:
3P
Power Loss:
at Rated Operating Conditions per Pole 115 W
Rated Current (In):
1600 A
Rated Operational Current (Ie):
1600 A
Rated Service Short-Circuit Breaking Capacity (Ics):
(240 V AC) 65 kA
(480 V AC) 65 kA
(600 V AC) 65 kA
Rated Uninterrupted Current (Iu):
1600 A
Rated Voltage (Ur):
600 V
Release:
PR121/P-LSI
Release Type:
EL
Short-Circuit Performance Level:
S
Standards:
UL 1066
Sub-type:
E2
Terminal Connection Type:
Fixed Circuit-Breakers
Rear flat Horizontal
Technical UL/CSA
Interrupting Rating acc. to UL1066:
(240 V AC) 65 kA
(480 V AC) 65 kA
(600 V AC) 65 kA
