Description
ACI4400/2HHP Ebm-Papst Fan Tubeaxial AC 100V to 240V, Square, 119mm x 38mm, Ball Bearing, 103CFM 3300RPM Axial Fan 5 Terminals RoHS
Specifications
Manufacturer: ebm-papst
Product Category: EC Fans
Type: Tubeaxial
Height: 105 mm
Depth: 38 mm
Width: 105 mm
Airflow: 103 CFM (2.9 m3/min)
Operating Supply Voltage: 90 VAC to 264 VAC
Noise: 43 DBA
Speed: 3300 RPM
Power Rating: 4.4 W
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Wire Leads
IP Rating: IP65
Series: ACi4400
Features: Tachometer
Bearing Type: Ball
Brand: ebm-papst
Current Type: EC
Product Type: EC Fans
Factory Pack Quantity: 1
Subcategory: Fans, Blowers & Accessories
Tradename: GreenTech
Unit Weight: 9.700340 oz
Part # Alias: ACI4400-2HHP
Improved, integrated, intelligent. The ACi4400 series is a fully compatible alternative to the classic 119 x 119 x 38 mm AC fans, simply upgrade the technology to reduce energy costs. The ACi4400 series has been designed to replace conventional AC fans that use low efficiency shaded-pole motors with GreenTech EC compact fans for the ultimate combination of high performance, compactness, and efficiency.
Features:
Air Exhaust Over Struts, CW Rotation Looking at Impeller
Electrical Connection Via 2 Flat Pins, 2.8mm x 0.5mm (0.11″x.02″)
Reinforced Composite; Impeller PA, Housing PBT, Non-Conductive & Non-Flammable
Electronic Locked Rotor Protection
Ball Bearings; Shielded & Lubricated for Life
Protection Level IP20
Flying Leads
Protection from Humidity, Splash Water or Salt Fog
Protection Level up to IP65 (Jacketed Cable Standard)
Speed Control and Tach Output
Highly Energy Efficient-Up to 75% Less Energy Consumption
Long Service Life – Up to 85% Longer
Available with Global Voltage Range of 100-240 VAC, Frequency Independent
Constant Speed Over the Total Voltage Range
Available with Protection Rating Up to IP65
Material: Fiberglass-Reinforced Plastic, Impeller PA, Housing PBT
Electronic Locked Rotor Protection
Air Exhaust over Struts, Direction of Rotation Clockwise, on Rotor
Electrical Connection Via 2 Flat Plugs 2.8 x 0.5mm, Flying Lead Optional
Mass: 0.55 lbs
Manufacturer:Electronic Components
Datasheet:ACi4400_2HHP.pdf
