Packaging Bulk
Series AEV01
Type Isolated Module
Number of Outputs 2
Voltage – Input (Min) 18V
Voltage – Input (Max) 24V
Voltage – Output 1 12V
Voltage – Output 2 -12V
Voltage – Output 3 –
Current – Output (Max) 1.05A, 1.05A
Power (Watts) – Manufacture Series 25W
Voltage – Isolation 500V
Applications ITE (Commercial)
Features Remote On/Off, OVP, SCP, UVLO
Mounting Type Through Hole
Package / Case 7-DIP Module
Size / Dimension 2.56″ L x 1.97″ W x 0.33″ H (65.0mm x 50.0mm x 8.5mm)
Operating Temperature -25C ~ 90C
Efficiency 86%
Manufacturer:Electronic Components
Datasheet:AEV01BB24.pdf
