Description
Unique features for CompM3
-Compatible with every generation of NVD
-New technology called ACET allows 50,000 hours of operation on one single battery (on setting 7 out of 10)
-500,000 hours of use on NVD setting
-Unequalled light transmission
-Submersible to 45 meters (135 feet)
-Comes with replaceable outer black rubber cover
-Outer rubber cover available in Dark Earth Brown
Standard features for all Aimpoint® sights
-Unlimited field of view
-Parallax-free with unlimited eye relief
-Unaffected by extreme weather conditions
-Rugged, durable construction
-No hazardous materials used
-No laser emission that could be harmful to your eyes
-Mechanical switch for speed and reliability
-Increased aiming confidence
-Reduced training time and ammunition
CompM3 TECHNICAL SPECIFICATIONS
OPTICAL DATA
-System: Passive Red Dot Collimator Reflex Sight
-Magnification: 1X
-Eye Relief: Unlimited
-Reticle Size: 2 MOA *
-Optical Coating: Anti reflex, 1st, 2nd and 3rd Generation NVD compatible (M2 only)
ELECTRONIC DATA
-Battery Type: One 3 Volt Lithium battery type 2L76 or DL1/3N
-Battery Life, Typical**: 50,000 hours at setting 7 out of 10
-Switch Dot Brightness: 10 settings – 4 NVD, 6 Daylight (1 is Extra Bright)
MECHANICAL DATA
-Housing Material: Extruded, high strength aluminum, hard anodized, black, non-glare finish Sight body and mount protected by a rubber cover, mat black
-Surface Finish: Hard anodized, matte, Dark Graphite Gray
-Lens Cover Material: Thermoplastic elastomer, black, non-glare finish
-Adjustment: 1 click = 10 mm at 80 meters = 13 mm at 100 meters = ½” at 100 yds
-Mounting: Aimpoint doesn’t sell Scopes with Mounts
DIMENSIONS
-Length: 130 mm (5.1” )
-Width / Height: 55 mm x 55 mm (2.2” x 2.2 ”)
-Ring Width: Max 30 mm (1.2″)
-Weight: 220 grams (7.8 oz) incl. lens covers. Rubber cover 50 grams (1.7 oz)
ENVIRONMENTAL DATA
-Temperature Range: -45 o C to +71o C (-50 o F to +160 o F)
-Water Resistance: 45 meters (135 ft)
*MOA (Minute Of Angle) 1 MOA = 30 mm at 100 meters = 1″ at 100 yards
**NEW ACET technology
Manufacturer Part Number: 2OA-COMPM3-SIGHT
