Description
Analog Devices ADV7123JST330 IC Digital to Analog Converter 330MHZ TRIPLE 10BIT HIGH SPEED VIDEO DAC LQFP-48
Specification
- Number of Channels : Triple
- Resolution : 10b
- Interface Type : Parallel
- Single Supply Voltage (Typ) : 3.3/5V
- Dual Supply Voltage (Typ) : Not RequiredV
- Architecture : Segment
- Power Supply Requirement : Single
- Output Type : Current
- Single Supply Voltage (Min) : 3V
- Single Supply Voltage (Max) : 5.25V
- Dual Supply Voltage (Min) : Not RequiredV
- Dual Supply Voltage (Max) : Not RequiredV
- Operating Temp Range : 0C to 70C
- Operating Temperature Classification : Commercial
- Mounting : Surface Mount
- Pin Count : 48
The ADV7123 (ADV®) is a triple high speed, digital-to-analog converter on a single monolithic chip. It consists of three high speed, 10-bit, video D/A converters with complementary outputs, a standard TTL input interface, and a high impedance, analog output current source.
Manufacturer:Analog Devices
Datasheet:Analog/ADV7123JST330.pdf
