Description
B190-110A0ASBE1 YUXI Header Connector 10 Positions 0.100″ (2.54mm) Through Hole
Features:
Key specifications/special features:
Positions: 06-64
Plastics height: 9.0mm
Current rating: 3.0A
Operating temperature: -40 to +105C
Contact resistance: 20m Ohms (maximum)
Insulation resistance: 1,000m Ohms (minimum)
Withstanding voltage: 500V AC
Insulator material: high-temperature thermoplastic (UL94V-0)
Contact material: brass
Dongguan Yuxi Electronic Co., Ltd., founded in 2003, specializes in producing precise connectors of board-to-board and wire-to-board of computers and electronic ancillary equipment.
Manufacturer:Electronic Components
Datasheet:B190-1XXXXXSXX1.pdf
