Description
BEAU 75505-C-49-50 TERMINAL BARRIER STRIP MODIFIED 355-4059-000 5 Circuit 0.375″ (9.53mm) Barrier Block Connector, Screws with Captive Plate
Terminal Block Type Barrier Block
Number of Circuits 5
Number of Wire Entries 5
Pitch 0.375″ (9.53mm)
Number of Rows 1
Current Rating 25A
Voltage Rating 300V
Wire Gauge 12-24 AWG
Top Termination Screws with Captive Plate
Bottom Termination PC Pin
Barrier Type 3 Wall (Tri)
Features –
Color Black
Terminal Screw Material Brass
Terminal Screw Finish Nickel
Mounting Type Through Hole
Operating Temperature 160°C
Material – Insulation Thermoplastic
Material Flammability Rating UL94 V-0
Beau™ Barrier Strips
Molex’s Beau™ barrier strips reduce assembly costs and improve interconnect performance
