Description
BMRA00050520100MA1 Chilisin Power-Inductor 10uH 20% 2A3 1Khz Closed Magnetic Circuit Type Molding Processing & for Ultra High Current SMD RoHS
Product detail
L(mm) : 5.4 0.35
W(mm) : 5.7 0.20
T(mm) : 1.8 0.20
Inductance(uH) : 10
Tolerance( %) : 20
Test Frequency : 100kHz,0.5V
RDC(O)Max : 0.18
Isat(A)Typ : 4
Irms(A)Typ : 2.3
Operating Temperature : -55C to 125C(Including self – temperature rise)
BMRx series is designed for low profile type with low RDC and ultra large current. Its molded magnetic shielded type is suitable for high-density mounting and ultra low buzz noise. Soldering conditions can be easily confirmed when mounting onto the board. This series also provides customers with embossed carrier type packaging for automatic mounting machine.
Manufacturer:Electronic Components
Datasheet:BMRx_Series.pdf
