Description
Bourns 4608X-102-103 Resistor, ISOLATED RESISTOR NETWORK, 4, 10KOHM, 2%, SIP, Product Range:4608X Series, Network Circuit Type:Isolated, No. of Elements:4, Resistance:10kohm, Power Rating per Element:300mW, Resistance Tolerance: 2%, No. of Pins:8, RoHS
Type Network
Technology Thick Film
Resistance 10kohm
Power Rating 1W
Power Rating Per Resistor 3/10W
Number of Resistors 4
Packaging Bulk
Tolerance (+ or -) 2%
Circuit Designator ISOL
Package / Case SIP
Mounting Style Through Hole
Temperature Coefficient ±100
Military Standard Not Required
Operating Temp Range -55C to 125C
No. of Terminals 8
Case Style Conformal
Failure Rate Not Required
Termination Style Pin
Terminal Pitch 2.54mm
Product Length (mm) 20.27mm
Product Depth (mm) 2.49mm
Product Height (mm) 5.08mm
Manufacturer:Bourns
Datasheet:4600X-series.pdf
