Description
BSC0702LSATMA1 Infineon MOSFET N-Channel 100A 83W Surface Mount PG-TDSON-8 RoHS
Specifications
Manufacturer: Infineon
Product Category: MOSFET
Technology: Si
Mounting Style: SMD/SMT
Package / Case: TDSON-8
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds – Drain-Source Breakdown Voltage: 60 V
Id – Continuous Drain Current: 100 A
Rds On – Drain-Source Resistance: 2.7 mOhms
Vgs – Gate-Source Voltage: – 20 V, + 20 V
Vgs th – Gate-Source Threshold Voltage: 2.3 V
Qg – Gate Charge: 30 nC
Minimum Operating Temperature: – 55 C
Maximum Operating Temperature: + 150 C
Pd – Power Dissipation: 83 W
Channel Mode: Enhancement
Tradename: OptiMOS
Packaging: Cut Tape
Packaging: Reel
Configuration: Single
Transistor Type: 1 N-Channel
Brand: Infineon Technologies
Forward Transconductance – Min: 60 S
Fall Time: 5.4 ns
Product Type: MOSFET
Rise Time: 4.8 ns
Factory Pack Quantity: 5000
Subcategory: MOSFETs
Typical Turn-Off Delay Time: 25 ns
Typical Turn-On Delay Time: 7.7 ns
Part # Aliases: BSC0702LS SP001589462
Unit Weight: 0.004180 oz
Manufacturer: Infineon Technologies
MFG Part #: BSC0702LSATMA1
