Description
Compression Lug, Straight, Standard Barrel, 2-Hole Mount, Copper, Tin Plated, For Code Copper Conductors, 2/0 AWG, 5/16 Inch Bolt Holes, 7/8 Inch Spacing, Coded Black, With Inspection Window, Voltage Rating: 600 -35000,Temperature Rating: 90 Deg C
Voltage Rating 600 – 35000 V
Type YA-2N, Code Conductor Long Barrel
Sub Brand HYLUG
Stud Size 1/2 IN Hole
Standard UL Listed At 90 DEG C, 600 V To 35 KV, CSA Certified, RoHS Compatible
Special Features Features: UL Listed 90 DEG C, 600 V – 35 KV, 45 DEG And 90 DEG Angles Are Available, Die Index: 13, Temperature Rating: 90 DEG C, Tongue Angle: Straight, Wire Strip Length: 1-9/16 IN, Finish: Electro-Tin Plated, Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W26VT, W26RT, X26RT Die, (4), Hydraulic: BCT500HS, Y500CTHS Tool, W26VT, W26RT, X26RT Die, (4), Y35, Y39, Y750, PAT750 Tool, U26RT Die, (2), Y46 Tool, U26RT Die With PUADP-1 Adapter, (2), Color Code: Black, Conductor Type: Commercial Stranded Copper, Dieless Tools (number Of Crimps): Y644HS Tool, (1), Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-3, MY29-11 Tool, (2), MRC840 Tool, (4)
Number Of Holes 2
Mounting 1-3/4 IN Stud Hole Spacing
Material Copper
Cable Size 2/0 AWG, 70 SQ-MM For Class 2 Conductor
Brand Name BURNDY
Application For Code Conductor
Manufacturer Part Number: YA26-2L
Manufacturer: 1-3/4″” Stud Hole Spacing
