Description
- High precision DC/DC-Converter galvanic insulated
- Built-in EMI filter
- Programmable Single Output, 10 to 200V
- PCB Mount
- Applicable for sensitive loads and piezo drives
| Model | DCV00081 |
| Power | 8 watt |
| DC Input | 10Vdc … 14Vdc |
| Connection | PCB mount |
| Input to Output Isolation | galvanic insulated |
| Programmable interface | 0 up to 10Vdc for programmable output |
| Efficiency typ. | > 65% |
| Ambient temperature | -20°C … +75°C |
| Cooling | Natural convection |
| Programmable DC Output | 10Vdc … 200Vdc |
| Output Current | 125mA power boost |
| Dimensions WxHxD | 60 x 17 x 60mm |
| Special Features | Synchrone master/slave operation |
| Continuous short circuit protected | |
| Low heat emission | |
| High reliability | |
| Excellent behavior at load switch | |
| Low inrush current |
Manufacturer Part Number: DCV00081-200
Manufacturer: Camtec
