Specification
Body Diameter: 7/32″
AECQ Electrical Polarization
Polarized
ABPM Body Diameter
0.219 inches maximum
ADAQ Body Length
0.608 inches maximum
AAQL Body Style
W/o mtg facilities, axial terminals
CQBQ Capacitance Value Per Section
10.000 microfarads single section
CWNJ Capacitive Electrode Material
Tantalum
CWSZ Case Insulation Material
Plastic
CWJK Case Material
Metal
CWQH Dc Leakage At Reference Temp
1.000 microamperes
CBBL Features Provided
Hermetically sealed case
CQJJ Nonderated Operating Temp
From -55.0 deg celsius and 85.0 deg celsius
CQWM Nonderated Continuous Voltage Rating And Type Per Section
50.0 dc single section
AARG Reliability Indicator
Established
AEBZ Schematic Diagram Designator
Electrode(s) grounded to case, w/gnd terminal
CWPN Power Factor At Reference Temp In Percent
6.0000
AEBT Terminal Diameter
0.025 inches
ABJT Terminal Length
1.500 inches
TTQY Terminal Type And Quantity
2 uninsulated wire lead
TEST Test Data Document
81349-milc3965/24 specification (includes engineering type bulletins, brochures,etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as “typical”, “average”, “”, etc.).
CRTP Tolerance Range Per Section
-20.00/+20.00 percent single section
Manufacturer Part Number: CL67BJ100MPG
Manufacturer: Electronic Components
