Description
ALTERA CPLD MAX 7000A Family 5K Gates 256 Macro Cells 166.67MHz CMOS Technology 3.3 Volt 100-Pin FBGA
EPM7256A and EPM7256AE Dedicated Pin-Outs ver. 1.0 100-Pin TQFP 100-Pin FineLine BGA 87 A6 INPUT/GCLRn 90 A5 TDI 4 A1 TMS 15 F3 TCK 62 F8 TDO 73 A10 GNDINT D6, G5 GNDIO (2) Dedicated Pin 144-Pin TQFP 208-Pin PQFP 256-Pin FineLine BGA T16 164
Manufacturer Part Number: EPM7256AEQC2085
Manufacturer: HTR Resistors
