Description
D100D31CR17101KR/LS374 CalRamic Technologies LLC General Purpose High Voltage Capacitor 100pF 10000V (10kV) ±10% N4700 Straight Through Hole Radial, Disc
Manufacturer: CalRamic
Capacitance: 100pF
Voltage Rated: 10000V (10kV)
Tolerance: ±10%
Temperature Coefficient: N4700
Size / Dimension: 0.310″ Dia (7.87mm)
Height Seated (Max): 0.480″ (12.20mm)
Lead Spacing: 0.374″ (9.50mm)
Lead Style: Straight
Mounting Type: Through Hole
Package / Case: Radial, Disc
Operating Temperature: 55°C ~ 125°C
Applications: General Purpose
Datasheet: D100D31CR17101KR/LS374
