Description
D1D20 Sensata-Crydom Solid State Relay, 3.5-32 VDC, SPST-NO, 20A/100V, DC Switching, 1-DC Series Panel Mount, Screw RoHS Product Specifications
Product Attribute Attribute Value Search
Contact Form SPST-NO
Control Voltage 32 VDC
Current Rating 20 A
Dielectric Strength 2500 V (RMS)
Function DC Switching
Maximum Ambient Temperature 80
Minimum Ambient Temperature -20 C
Mounting Type Panel Mount
Number of Pins 4 Pin
Primary Type Solid State Relays
Product Description Featuring state-of-the-art surface mount technology, the relay delivers proven reliability in the most demanding applications. Output consists of an SCR AC switch. ISO 9001 Certified facility for optimum product performance and reliability.
Product Header 1-DC Series Solid State Relay
Relay Type Solid State
Series 1-DC Series
Standards UL ; CE
Termination Screw
Voltage Rating 100 VDC
DC output relays feature MOSFET technology for low on-state resistance, assuring easy paralleling and switching capabilities to 40 A at 100 VDC. Lower current models are also available to 500 VDC. All models come in Crydoms standard panel-mount package. Operating Temperature Range: 30C to 80C. Isolation Voltage (VAC): 2500.
Features:
DC Output, Low On-State Resistance
Paralleling Capability for Higher Currents
UL Approved on 100 V Models Only
Crydom panel mount, DC output solid-state relay
3.5-32Vdc input
1-100Vdc / 20A output
Low-impedance MOSFET output for reduced power dissipation
Epoxy-free design enhances overall reliability by eliminating stress on internal components
Agency approvals; cURus Recognized, CE
^^With MOSFET output, this 1-DC Series Panel Mount DC Solid State Relay offers reliable fast switching of DC loads through low On-State resistance. Power ratings for this DC output SSR range up to 100 Amps at 100 VDC and 10 Amps at 500 VDC.^
