Description
Specifcation
Termination SMT
Operating force 2.6 N
Model Construct Rightangle
Sealing IP40
Dimension 7,2×7,0 mm
Total high/long L9,9 mm
Operating temp. -25 to 70C
Operating life 200000 cycles
max.Volt/Switch 12 VDC
max.I / Switch 50 mA
Illuminated No Y/N
Actuator size 3.5 mm
Contact type SPST-NO
Button version Round
Ground Yes Y/N
Pitch 4.5 mm
Plating Ag
Automotive NO
Leadfree Defin. RoHS
Manufacturer:Diptronics
Datasheet:Diptronics/DTSAMG-6-Q.PDF
