Description
AC 3200 JH EBMPapst Fan Tubeaxial 115VAC Square – 92mm L x 92mm H Ball 86.0 CFM (2.41m³/min) 2 Wire Leads
Manufacturer
ebm-papst Inc.
Series
Green Tech ACmaxx, AC3200J
Packaging
Box
Part Status
Active
Voltage – Rated
115VAC
Size / Dimension
Square – 92mm L x 92mm H
Width
38.00mm
Air Flow
86.0 CFM (2.41m³/min)
Static Pressure
–
Bearing Type
Ball
Fan Type
Tubeaxial
Features
Electronic Commutation (EC), Locked Rotor Protection
Noise
55.0dB(A)
Power (Watts)
11.00W
RPM
6800 RPM
Termination
2 Wire Leads
Ingress Protection
IP20
Operating Temperature
-4 ~ 158°F (-20 ~ 70°C)
Approval Agency
CCC, CE, CSA, UL, VDE
Weight
0.716 lb (324.77 g)
Current Rating (Amps)
–
Voltage Range
85 ~ 265VAC
Material – Frame
Polybutylene Terephthalate (PBT)
Material – Blade
Polyamide (PA), Nylon, Fiberglass Reinforced
Lifetime @ Temp.
70000 Hrs @ 40°C
Base Product Number
AC3200
