Description
4550N EBMPapst AC Fan 230VAC; 119x119x38mm; 145m3/h; 44dBA; slide; 2550rpm Axial
Manufacturer ebm-papst
Minimum Operating Temperature -10 °C
Maximum Operating Temperature 55 °C
Noise Level 44 dBA
Manufacturer Part Number 4550N
Series 4000 N Series
Voltage Rating 230 V
Power Rating 16.5 W
Approximate Size 119 x 119 mm, 4.7 x 4.7 in
Rotation CW Degree(s)
Speed 2550 RPM
Air Flow 85.3 CFM
Configuration Square
Termination Flat Plugs
Size 4.69 x 1.5 (119 x 38) In. (mm)
Material Aluminum
Type Square
Frequency 50 Hz
Fan Type AC
Weight 0.55 kg
Approximate Thickness 1.5 in, 38 mm
AC fans with external rotor shaded-pole motor. Impedance protected against overloading.
Metal fan housing and impeller
Air intake over struts. Direction of rotation clockwise, seen on rotor. Types 4890 N and 4840 N air exhaust over struts.
?Electrical connection via 2 flat plugs 3.0 x 0.5 mm.
Impeller with 3 or 5 blades, see note for fan type.
Optionally available: Models with reinforced flanges and single leads.
Fan housing with grounding lug for screw M 4 and UNC.
Mass: 550 g.
Please note our new ACmaxx Series. With identical mounting dimensions and voltages, this Series achieves higher energy efficiency
