Description
EC8038TH24BP Evercool DC Fan 24V 1.5A 131.24 CFM Axial 80x80x38mm 4 Poles RoHS
Evercool PWM fan creates outstanding static pressure and focuses the airflow for superior performance on coolers and other applications. Evercool PWM fan uses high quality PWM IC for fully automatic control guarantee astounding quietness of operation.
Specifications
DC Fan Size : 80 x 80 x 38 mm
Bearing Type : Dual Ball bearing
DC Fan Speed : 10000 +- 10%RPM
Life Time : Over 50,000 hr
Noise Level : < 69 dBA
Rated Voltage : 24 V.DC
Airflow: 131.24 CFM(ft3/min)
Rated Power Consumption: 36W
Type:Axial Flow Fan
Applicable Industries:Machinery Repair Shops, Farms, Restaurant, Retail, Printing Shops, Energy & Mining, Food & Beverage Shops
Electric Current Type:DC
Mounting:Free Standing
Size:80*80*38MM
Usage:Industry Greenhouse
Power Supply:Electric Power
Color:Black
Product name:cooling Fan
Bearing Type: ball bearing
Manufacturer:Electronic Components
Datasheet:EC8038TH24BP.pdf
