Description
F-2815-031-B80 – .003″ Precision Noryl Orifice Restrictor with 1/16″ Barbs (Gold)
Precision molded orifices feature accuracy comparable to jewel orifices at a fraction of the cost. Color coded for easy identification. Barbed connections allow higher working pressures.
Specifications
Accuracy: Orifice Size .003
Material: FDA Approved Noryl
Max Operating Pressure: 100 PSI
Connection: Straight Connection for 1/16″ I.D. Tubing
Repeatability: .0002″ or 3% Flow whichever is greater
Manufacturer: Electronic Components
MFG Part #: F-2815-031-B80
